Operation

5.1

Control pendant

Hoists may only be operated by persons who have been assigned this task by the
NOTE operator. The Operating instructions must always be located next to the hoist and
accessible to the operating personnel.
Emergency stop button
Idle
Lifting
Lowering
Travel to the right
Travel to the left
Diagram No 29: Pendant control (example)
Push-button
Mushroom-shaped push-button -
emergency stop
Direction push-button single speed
Direction push-button two speeds
Pre-selector switch
Table No. 3: Push-button functions
Diagram No 30: Fastening the strainer clamp
The strainer clamp must be fastened in way not to allow any tensile forces to act on the
CAUTION
control cable. Do not pull the hoist by holding the pendant control or the control cable.
Push the button or hit it
Turn clockwise
Push the button
st
Push the 1 stage of the button
st
Push the 2 stage of the button
Dial switch
Left - middle - right position
Strainer clamp for control cable
Control cable
Control pendant
Function
Off
Unlock
Movement in a direction
Movement in the chosen direction
at slow speed
Movement in the chosen direction
at fast speed
According to the pre-selection option
