Initial Settings on NAVpilot-711C

(1) In the Installation Menu, access [Installation] –

[SHIP'S CHARACTERISTICS] – [BOAT TYPE] and

select [EVCS BOAT].

Selecting the [EVCS BOAT] will allow the

NAVpilot-711C system to communicate with the

Yanmar VC10 system via the IF-NMEA2K2.

(2) Set the [Boat Length], [Cruising Speed], and [Rate

of Turn] to fit the customer's boat characteristics.

(3) Set the [Boat Length], [Cruising Speed], and [Rate

of Turn] to fit the customer's boat characteristics.

You do not need to perform the rudder limit setup and

rudder test because those values are already fixed by

the Helm Master system.

The NAVpilot-711C is compatible with the Yanmar VC10 with the following software

versions. Make sure to install the latest versions of both processor and control units in the

correct combination, as well as the appropriate IF-NMEA2K2 serial number and version.

Processor Unit FAP-7002

Control Unit FAP-7001/7011 (Monochrome)

Control Unit FAP-7011C (Color)

IF-NMEA2K2 (S/N: 5611 to 5650, 5791 and later)

Items

Versions

01.26 or later

01.16 or later

01.07 or later
