PC Driver Install & Software Update Procedure
To update the NavPilot software, you will need the following items:
Laptop or Desktop PC with available USB port
USB cable with a Male type-A connector at one end and a Male type-B connector
at the other end.
2 zipped software folders labeled as follows.
_udp_p.zip
(This contains both the Application and Boot software for the NavPilot processor unit)
_udp_c.zip
(This contains the Application software for the NavPilot control unit)
Connect the USB cable between the PC and the NavPilot Processor with all
Control unit(s) connected.
Connect the NavPilot Processor to vessels 12 / 24 VDC supply.
NavPilot 700 / 711 / 720
Page 1
FURUNO U.S.A., INC.
www.furunousa.com
Camas, WA
(360) 834-9300
USB cable
12 / 24 VDC Power Source
Denton, MD
(410) 479-4420
Advertisement
Related Manuals for Furuno NavPilot 700
Summary of Contents for Furuno NavPilot 700
- Page 1 Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 NavPilot 700 / 711 / 720 PC Driver Install & Software Update Procedure To update the NavPilot software, you will need the following items: Laptop or Desktop PC with available USB port USB cable with a Male type-A connector at one end and a Male type-B connector at the other end.
-
Page 2: Pc Driver Installation
PC Driver Installation If your PC has never been used to update a NavPilot 700, 711 or 720 in the past, the Driver software must be installed on you PC before you will be able to update the NavPilot software. Continue reading below and follow the instructions for installing the PC Driver software. - Page 3 FURUNO U.S.A., INC. www.furunousa.com Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 5. Select the path to the “NAVpilot-700.inf” file, using the Browse button and click Next. (Included in both zipped folders). 6. Click “Continue Anyway”. Page 3...
- Page 4 9. Wait until the Found New Hardware Wizard completes the driver installation and then click “Finish”. With the NavPilot PC Driver installation complete, you may now proceed to the NavPilot 700 / 711 / 720 Software Update Procedure on the next page.
- Page 5 (360) 834-9300 (410) 479-4420 NavPilot 700 / 711 / 720 Software Update Procedure After installing the driver software on the PC, the NavPilot 700 / 711 / 720 can now be updated using / 711c the steps detailed below. There are a total of updates that need to be completed.
- Page 6 FURUNO U.S.A., INC. www.furunousa.com Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 c) Wait for the Pilot to restart. (The pilot will restart after the update is complete). d) When the message, “Press any key to continue…” appears, do so to close the window and complete the update.
- Page 7 FURUNO U.S.A., INC. www.furunousa.com Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 f ) Open the _upd_c folder. g ) Double-click on UP.BAT to begin updating the Control Unit software version. Page 7...
- Page 8 FURUNO U.S.A., INC. www.furunousa.com Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 h ) Wait for the Pilot to restart. (The Pilot will restart after the update is complete.) i ) When the message, “Press any key to continue…” appears, do so to close the window and complete the update.
- Page 9 FURUNO U.S.A., INC. www.furunousa.com Camas, WA Denton, MD (360) 834-9300 (410) 479-4420 5. Check the program numbers in the diagnostic display as follows: a) Start with the NavPilot powered on and in the STBY display. b) Press the MENU key.
