- Page 1 Hardware Installation Guide CardPark APA-4510 ISA-to-PCMCIA Card Adapter for Desktop PCs...
-
Page 2: Getting Started
™ The CardPark adapter designed for accessing PCMCIA cards from your desktop PC. This guide explains how to install the APA-4510 in your PC. The following is a list of requirements: An IBM-AT compatible PC DOS 5.0 or above Microsoft Windows 3.1 or above (optional) - Page 3 Installing the PCMCIA Card Adapter WARNING: power to your PC and attached devices before you begin. Touch an unpainted surface of your PC chassis; this allows any static electricity in your body to be dispersed and prevents damage to components. Remove the PC’s chassis cover.
- Page 4 Make sure the circuit board in the card adapter is facing upward and that the cables are securely attached to the card adapter. Insert the card adapter (or card adapter with mounting bracket) into the front of the drive bay, guiding the cables out the back of the drive bay.
- Page 5 Slot 2 Pin 1 Slot 1 Pin 1 Connecting the Cables from the Card Adapter to the Hold the two connectors together tightly on the ribbon cable from Slot 2 on the card adapter and connect it to the 100-pin header on the ISA-bus host adapter labeled Slot 2.
-
Page 6: Troubleshooting Checklist
guide for aligning cards, be sure the end of the adapter is inserted in the card guide. Inserting the ISA-Bus Host Adapter Carefully press the ISA-bus host adapter down into the slot. Secure the adapter bracket to the PC chassis with the screw from the removed expansion slot cover. -
Page 7: Troubleshooting Tips
We offer the following support and information services: For technical support (answers to technical questions, informa- tion about the Adaptec BBS, and access to the Interactive Fax system), call 800-959-SCSI (7274) or 408-945-2550, 24 hours a day, 7 days a week. To speak with a product support represen- tative, call 408-934-SCSI (7274), M–F: 6:00 a.m. -
Page 8: Fcc Compliance Statement
Adaptec, Inc. 691 South Milpitas Blvd. Milpitas, CA 95035 Copyright © 1994, Adaptec, Inc. All rights reserved. Adaptec, the Adaptec logo, and APA are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. All other trademarks used are owned by their respective owners.
