Table 4: Entering Temperature Setpoints
Press MENU from the Status
RoomTemp
Display Menu to enter the Main User
75.0°F
Menu.
Answer NO to all prompts until the
temperature set prompt appears in
Temperat
the display (it may be the first
set? Y/N
prompt). Press YES to enter
temperature setting menu.
Press YES to change occupied
Cooling
cooling setpoint. Press NO to
set? Y/N
advance to occupied heating
setpoint menu.
Use the UP/DOWN arrow keys to
Cooling
set temperature. Press YES to store
75.0°F
value and advance to next menu.
Press YES to change the occupied
Heating
heating setpoint. Press NO to
set? Y/N
advance to unoccupied cooling
setpoint menu.
Use the UP/DOWN arrow keys to
Heating
set temperature. Press YES to store
68.0°F
value and advance to next menu.
Press YES to change the
Unocc CL unoccupied cooling setpoint. Press
set? Y/N NO to advance to the unoccupied
heating setpoint.
14 TEC2103-1 Networked Multi-Stage Thermostat Installation Instructions
Use the UP/DOWN arrow keys to
Unocc CL
set temperature. Press YES to store
80.0°F
value and advance to next menu.
Press YES to change the
Unocc HT
unoccupied heating setpoint. Press
set? Y/N
NO to advance to temperature
display units.
Use the UP/DOWN arrow keys to
Unocc HT
set temperature. Press YES to store
62.0°F
value and advance to next menu.
Press YES to set the display units to
°F/°C
°F or °C. Press NO to advance to
set? Y/N
temperature setpoint type menu.
This only changes the local display.
Setpoint
Press YES to select the setpoint
type Y/N
type (permanent or temporary).
Using the UP/DOWN arrow keys
select the setpoint type (see the
Setpoint
Setpoint Type section for a
permnent
description of choices). Press YES
to enter the choice.
Press YES to return to the Status
Exit?
Display Menu or NO to re-enter the
Y/N
temperature setting menu.
