ASSEMBLY INSTRUCTIONS FOR 2B2 PORTABLE FUTSAL SOCCER GOAL
1. Unpack all parts and check for damage that may have occurred during shipping. If damage has occurred,
notify trucking company immediately. Lay out all parts. Remove all cardboard and packaging immediately.
Wet or damp packaging may damage contents.
2. Read through entire instruction before beginning assembly and installation.
3.
If goal is to be used in a portable application continue to step 4. If goal is to be used in a more permanent
application skip steps 4 through 6 and begin assembly with step 7.
Net Fastener (1)
(Part# VZ229)
All Kwik Goal products carry a Lifetime Guarantee. For help with
guarantee issues, visit kwikgoal.com and click on the Lifetime
Guarantee logo or contact customer service at
Post (2)
(Part# UZ510)
Base (2)
(Part# UZ527)
Net (1)
(Part# 3B1)
140 Pacific Drive Quakertown, PA 18951
(P) 215-536-2200 / (P) 800-531-4252 / (F) 215-536-4309 / (F) 800-778-8869
Visit our website @ kwikgoal.com
Ground Anchor (4)
(Part# TZ150)
2007, Rev. 2011 Kwik Goal Ltd.
.
1-800-531-4252
Rail w/ swage (2)
(Part# UZ509)
Rail w/o swage (2)
(Part# UZ493)
Rubber Pad (5)
(Part# VZ188)
NZ73 Rev. 01/13/11
