- Page 1 Info Version 3.6 for LZ/LZV100 and LH100 04 08...
- Page 2 Update LZ100 / LZV100 and LH100 to Version 3.6 New and changed features in version 3.6 Here is an overview of the new or changed features: • Fast change between up to 12 freely selectable locomotive addresses with the 'Esc' key. •...
- Page 3 Changes to the LH100 Changes to the LH100 Due to the new functions we have made some changes to the display and operation of the LH100. These changes are described below. Display when controlling a locomotive The arrow indicates the direction of motion: Arrow upward: forward Arrow downward: backward Lines indicate the function groups:...
- Page 4 Update LZ100 / LZV100 and LH100 to Version 3.6 2.1.1 Examples for the most important displays: The single locomotive (L) with address 0003 is controlled. The display of function group 1 is selected; functions 0, 1, 3 and 8 are activated.
- Page 5 Changes to the LH100 Release 'Esc' display locomotive address placed in this slot. Press 'Esc' again to change to the next stack slot … ... and to display the locomotive address placed in this slot..Continue until the last stack slot is displayed.
- Page 6 Update LZ100 / LZV100 and LH100 to Version 3.6 Select 'SYS'. Select 'Setup'. The current stack size is displayed. Decrease the stack size with '-'. Decrease the stack size with '-'. Increase the stack size with '+'. Confirm your selection. Return to the 'SYS' menu.
-
Page 7: Changing Function Groups
Changes to the LH100 Key: Function group 1: Function group 2: 10 11 12 13 14 15 16 17 18 19 Function group 3 20 21 22 23 24 25 26 27 28 The bottom line of the display shows the function status: If the function number is visible, the function is activated;... -
Page 8: Configuring Locomotive Decoder Functions
Update LZ100 / LZV100 and LH100 to Version 3.6 Configuring locomotive decoder functions Functions F1 to F12 of the locomotive decoder can be set to continuous or temporary operation. Continuous operation Temporary operation Press the key to activate the Press the key to activate the function;... - Page 9 Changes to the LH100 Press 'Enter' to complete the entering process and store the new setting in the command station. Press 'Esc' to return to controlling the locomotive without storing the setting. 'Refreshing' functions By 'refreshing' functions we mean the following: In defined regular intervals the command station sends function information via the track to all decoders located on the track.
-
Page 10: Displaying And Changing The Speed-Step Mode
Update LZ100 / LZV100 and LH100 to Version 3.6 Functions F0 to F20 are transmitted cyclically. Functions F0 to F28 are transmitted cyclically. Functions F0 to F4 are transmitted cyclically. Press 'Enter' to confirm your selection. Displaying and changing the speed-step mode To display or change the speed-step mode, proceed as follows: Select the address of the locomotive whose speed-step mode you want to... - Page 11 Changes to the LH100 Press 'Enter' to assign a specific speed-step mode to the locomotive address. If the speed step of the locomotive is not 0, the speed-step mode currently set will be displayed while you press '+' and cannot be changed.
- Page 12 Update LZ100 / LZV100 and LH100 to Version 3.6 Enhancements for programming on the programming track With version 3.6 you can enter and read CVs from 1 to 1024 on the programming track. Depending on the selected CV, the display shows: CV 1 –...
- Page 13 Changes to the LH100 Enhancements for programming in operational mode (PoM) 2.9.1 Fast changing of a CV Select the address of the locomotive whose features you want to change via PoM. The menu that was selected last is displayed The programming mode that was selected last is displayed.
- Page 14 Update LZ100 / LZV100 and LH100 to Version 3.6 2.9.2 Fast changing of a CV value If you have selected a CV or entered and confirmed a value with 'Enter' during programming in operational mode, you can increase or decrease this value simply with '+' or '-'. The new value will be entered immediately into the decoder.
- Page 15 Changes to the LH100 Use '-' to scroll to ’CV’. Enter the number of the CV whose value you want to change. The value for the starting delay is stored in CV3. The address display LRC120 displays the value of CV3 for approx. 3 seconds.
- Page 16 We reserve the right to make changes in line with technical progress, product maintenance or changes in production methods. Hüttenbergstrasse 29 35398 Giessen Hotline: 06403 900 133 Fax: 06403 900 155 www.digital-plus.de www.lenz.com info@digital-plus.de Please keep this information or future reference!
