HP Procurve Secure Router 7203dl Product End-Of-Life Disassembly Instructions page 2

Tool Description
Flat Head Screw Driver
Phillips Head Screw Drive
Nutdriver
Torx Screwdriver
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove "Encryption Module" labeled rear plate using Flat head screwdrive
2. Remove screws securing top cover using Phillips Screwdriver
3. Remove top cover
4. Remove screws securing the "Console" RS-232 connector using Nutdriver
5. Disconnect cables attaching fans to PCA
6. Remove screws securing PCA to sheet metal using Phillips Screwdriver
7. Separate the PCB and screws
8. Remove screws attaching fans to sheet metal using Torx T9 screwdriver
9. Remove fans from sheet metal
10. Unscrew and remove front metal covers marked "Slot 1", "Slot 2" and "Slot 3" (if installed)
11. Using flat screwdriver pry-off plastic "Power/Fault" from front left sheet metal
12.
13.
14.
15.
16.
17.
18.
19.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
EL-MF877-00
Template Revision A
Tool Size (if
applicable)
3/16"
P1
P6 - 3/16"
T9
