DigiPREP DISMANTLING PROCEDURES

This section deals with dismantling the unit to
gain access to the components inside. There have
been several electrical revisions to the DigiPREP
systems. If you do not fi nd instructions for your model,
continue reading.

REMOVING THE CORIAN RING

1. Turn the DigiPREP Block on its side to obtain
the key
• If you fi nd an aluminium T: Continue to step
2.
• If you don't fi nd an Aluminium T: The Corian
ring is designed to lift off the top of the
instrument manually. Pull up gently on each
corner until the top lifts off, and continue to
'Removing the graphite block'.
KeyPad
74
Version 1.0
2. Insert the key into one of the slots located
beside the rubber feet.
3. Push the aluminium T into the slot until the
Corian ring begins to lift.
4. Repeat process for the three remaining clips,
and return the aluminium key to the base of the
unit.
NOTE
SCP SCIENCE
If you are missing your aluminium
key, a substitution such as a fl at
head screwdriver will also work.
