COMPONENTS AND INSTRUMENT DESCRIPTION

2
3
1. Power light (LED)
2. LCD screen
3. KeyPad
4. Connection port for umbilical cord (to block)

UNPACKING

Retain all packing material in case
NOTE you need to return the instrument to
the manufacturer for service.
1. Verify that all components listed have been
included:
• DigiPREP keypad controller
• Power cord
DigiSET dongle
•
1
8
SCP SCIENCE
4
6
5 5. Power cord receptacle Power cord
6. Power Switch
7. DigiSET connection port
8. Detachable Power Cord
Inspect the products for any shipping damage.
If the instrument has been damaged in shipping,
contact the freight carrier to report damage and to
fi le a damage report. Also contact the SCP
SCIENCE service department to report damage
and to request service information (see page 88 for
contact information).
If damage is noted, do not attempt
WARNING
to operate the instrument.
7
5
KeyPad
