Acnodes RMC 6015A Specifications

» Specifications
Construction:
1U rack nuit height
System Board:
Processor:
Dual 771-pin LGA Sockets
Supports up to two Intel® Dual-Core Xeon® processor(s)
of the same type below:
Dual-Core Intel® Processor 5100/5000,
2MB L2 Cache per core, 4MB L2 cache total, up to 3.73 GHz,
System Bus: 1333 / 1066 / 667 MHz system bus
Memory: 6 x 240-pin 667/533MHz DDR2 socket, up to 16GB
memory
SATA: Intel ESB2 SATA 3.0Gbps Controller, RAID 0, 1, 5, 10
support
SATA ports: 6 x Serial ATA ports
IPMI: Support for Intelligent Platform Management Interface
v.2.0
IPMI slot: 200-pin IPMI slot (SIM1U)
LAN: Intel® (ESB2/Gilgal) 82563EB Dual-Port Gigabit Ethernet
Controller
Video: ATI ES1000 controller with 16 MB of video memory
2 x USB ports
1 x Serial and 1x parallel ports
Devices:
2 x SATA hot-swap open drive bay
1 x slim-type CD-ROM bay, 8X DVD (STD)
Expansion slot:
1x 64-bit 133/100MHz PCI-X Slot
Front Panel Controls:
Power on/off switch
System reset button
Front Panel LCD Indicator:
1 x Power LED
1 x Hard drive activity LED
2 x Network activity LEDs
1 x System Overheat LED
I/O ports:
1 x serial port
1 x parallel port
2 x RJ-45 ports
2 x PS/2 ports
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
RMC 6015A
1U rack mount computer
Dual-core Intel XEON system
2 x SATA hot-swap driver bay
1 PCI expansion slot
» Features
» 1U rackmount computer, only 22.6" depth
» Dual-Core intel XEON processor with 1 x PCI-X expansion slot
» Built-in video and dual 10/100BT LAN
» Built-in Intel ESB2 SATA 3.0Gbps Controller, RAID 0, 1, 5, 10
» 2 x hot-swap SATA and 1 x slim-type CD-ROM open drive bay
» Built-in 520W 110/220VAC Power supply
Cooling Fan:
2 x 10cm ball-bearing fan
Mounting Slide Rail:
1 x rack mounting slide rail
Power supply:
520W AC power supply w/ PFC AC Voltage
100 - 240V, 50 - 60Hz, 7 - 3Amp
+5V, 20 Amp, +5V standby 3 Amp
+12V 39 Amp, -12V 0.5 Amp
+3.3V 16 Amp
Environmental:
Operating Temperature Range: 10 - 35°C (50° to 95° F)
Non-Operating Temperature Range: -40 - +70°C (-40° to 158° F)
Humidity Range: 8 - 90% non-condensing
Non-Operating Humidity Range: 5 - 95% non-condensing
Color:
Black
Gross Weight:
40lb
Dimension:
19"(W) x 22.6"(D) x 1.75"(H)
» Options
CDRW-S: Silm-type CDRW
SL20: 20" slide rail
» Ordering Guide
RMC 6015A:
1U Dual-core XEON whit 2 SATA HD rackmoumt computer
