- Page 1 Lenkrad Interface Steering wheel interface Bedienungsanleitung Instruction manual 67674 Audiotechnik Dietz Vertriebs-GmbH ● Benzstr. 12 ● 67269 Grünstadt ● info@dietz.biz ● www.dietz.biz ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013...
-
Page 2: Table Of Contents
Technical data ................................. 9 Allgemeine Hinweise Sehr verehrter Kunde, vielen Dank, dass Sie sich für ein Produkt der Firma Audiotechnik Dietz entschieden haben. Sie haben eine hervorragende Wahl getroffen. Bei der Entwicklung des Produktes wurde besonders auf Ihre persönliche Sicherheit, kombiniert mit bestmöglichstem Bedienungskomfort, modernem Design und aktuelle Produktionstechniken geachtet. -
Page 3: Allgemeine Sicherheitshinweise
Verletzung des Auges führen kann. Achtung ! Legen Sie keine Magnete oder magnetische Werkzeuge auf die Artikel. Dies kann zur Beschädigung des Artikels oder Datenverlust führen. ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013... -
Page 4: Hinweise Auf Voraussetzungen Für Den Bestimmungsmäßigen Betrieb
3. Adapterkabel 6700X mit dem freien Anschluss am Lenkradinterface verbinden. 4. Lenkradadapterkabel 6700X mit Lenkradfernbedienungsanschluss des Radios verbinden. 5. Die Steuerleitungen (weiß, lila und grau) sind beim 67674 bereits fertig mit dem 16-poligen Anschlußstecker verkabelt. Bitte kontrollieren Sie die Kabelverbindung anhand der untenstehenden Tabelle. -
Page 5: Wartungshinweise
Lila, Leitung C blau/silber grün/schwarz schwarz/braun grau/rot oder gelb/grün Kompatible Geräte zur Adaption der Lenkradfernbedienung mit 67674 über radiospezifischen Adapter: 67001: ALPINE 67002: BLAUPUNKT 67003: CLARION 67004: JVC 67005: KENWOOD 67006: PANASONIC 67007: PANASONIC AV Geräte 67020: PIONEER –... -
Page 6: General Advice
General advice Dear client, many thanks for having chosen an Audiotechnik Dietz product. You have made a magnificent choice. While developing this product, your personal safety combined with the best operating service, modern design and an up-to-date production technique was especially taken into account. -
Page 7: General Safety Instructions
Risk of eye injury. Attention! Do not use any magnetic part or lay down a magnet to the unit. Danger of lost files or damaged units. ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013... -
Page 8: References Of Legal Regulations For Operation
6. Connect the interface cable kit with the car connector and the head unit. 7. Reinstall the radio. RCA – Cable setting Red = front right White = front left Black = rear right yellow = rear left ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013... -
Page 9: Service Notes
70 x 40 x 20 Cable length approx. 200 mm This unit is only for automotive use and has therefore a lifetime of max. 10 years. ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013... - Page 10 _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ _________________________________________________________________________________________ ® Copyright © by Audiotechnik Dietz Vertriebs-GmbH ● Germany Rev 4, Stand: 07 / 2013...
