User Manual
» Specifications
Front panel:
Material Aluminum Front Panel with Steel Chassis
Front Panel NEMA 4 or IP65-rated
(blcak with fairness &sand blast process)
LCD Panel:
Type 15" TFT Sunlight Readable
Resolution 1024 x 768 Colors 65G (36 bits)
Luminance 350 cd/m2
Contrast ratio 400 :1
Backlight MTBF 30,000 Hrs
LCD Panel MTBF 50,000 Hrs
Touch Screen:
USB type resistive-type touch screen
3 gram activation pressure
Light transmission 75% typical
Chemical / Solvent / Abrasion resistant
P-4 PC System:
CPU: Socket 478 Pentium 4 up to 3.06Ghz
Memory: 1 x 184-pin DIMM, 1GB DDR memory
SSD:
Optional for Disk-On-Chip or Flash Disk Compact Flash Type 2
Socket
1 x 3.5" internal Hard Disk drive bays
1 x slim-type CD-ROM
1 x slim-type 1.44MB FDD
1 x Intel 82541 10/100/1G Ethernet Controllers
1 x AC '97 Codec, with line-in/out, mic
1 x Intel 845GV, onboard video
Watchdog Timer:
Software-programmable watchdog timer
System Fan:
1 x system Fan
I/O Ports:
4 x RS-232 ports, (COM2 selecable RS-232/422/485)
1x parallel port
2 x PS/2 Ports (Keyboard & mouse)
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
PC 5151
15" 1024 x 768 Touch Panel PC
Intel P4 all-in-one system
3 PCI/ISA expansion slots
» Features
» 15" TFT 1024 x 768 300nit VGA LCD
» Resistive type touch screen
» Aluminum NEMA 4 rated front beige color bezel
» Intel® Socket 478 533FSB, P4 system board
» Built-in slim-type 1.44MD FDD, CD-ROM
» Built-in 3.5" IDE type HD
» up to 3 x PCI / ISA expansion slots
1 x D-sub 15-pin VGA ports
1 x D-sub DIO port
2 x USB ports,
1 x RJ45 port
1 x MIC, 1 x Line-in, 1 x speaker port
Optional for Compact-Flash slot
Expansion Slot:
Optional for 1PCI/1ISA or 3PCI/3ISA expansion box
Power Supply:
90-264VAC full-range, 200W with Power Factor Correction
Weights:
26 lbs
Dimension:
15.6" (W) x 11.7" (H) x 3.89" (D)
Environmental:
Operating Temperature 0ºC to 50ºC
Operating Humidity:
5% to 85%, @ 40ºC non-condensing
Safty:
CE, FCC
» Options
EX-2: 2 x PCI expansion slots
EX-3: 3 x PCI expansion slots
RM-5151: 19" rackmount kits
» Ordering Guide
PC 5151:
15" 1024 x 768 P4 touch Panel PC
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
