Acnodes KDS 6198 Specifications

» Specifications
Material:
Heavy-duty steel
Keyboard and track ball (USB-type):
101 keys keyboard with 10keys key-pad
Sun keys:
STOP, HELP, AGAIN PROPS, UNDO, FIND, OPEN COPY, CUT, PASTE
and FRONT
3-buttons track ball
LCD Panel:
Size: 19"
Resolution: 1280x1024
Sun resolution: 1152x900
Atuo switch between Sun and PC display resolution
Brightness (cd/m^): 250nit
Contrast Ratio: 700 : 1
Response time:
Tr=15ms/ Tf=10ms
Pixel pitch: 0.242mm (H) x 0.242mm (W)
Viewing Angle: 170° Horizontal and 170° Vertical
Backlighs: 4 CCFTs
Colors: 16.7M colors
MTBF: 30,000 hours
KVM Switch:
8 port USB KVM switch
Connector type: proprietary DB-15 KVM connector
Cascades level: 8 levels, up to 128 servers
built-in microprocessor to emulation for each port boots up
processor
Input VGA resolution: 1,920 x 1,440
Auto Scan Mode: monitoring your server at interval 5 to 99s
Supprt hot-pluggable cable and built-in KVM switch buttons
Multi-platform: Suns, PCs, IBMs, HPs, Compaq & DELL
KVM switch Connector:
8 x D-Sub 15 pin (female) for VGA / Keyboard / Track ball
(drawer side)
1 x D-sub 15 pin for cascades port
20947 Currier Road Suite #H
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
KDS 6198
19" 1280 x 1024 / 1152 X 900 LCD
SUN-keys keyboard / track abll
8 port USB KVM switch
» Features
» 1U compact design, only 23.6" depth
» 19" 1280 x 1024 / 1152 x 900 LCD
» OSD (On Screen Display) function
» 101 keys keyboard with built-in Sun keys & 10-keys keypad
» 3-buttons track ball
» 8 port USB KVM switch
» 110/220VAC power adapter
Cable:
8 x 6' cable for VGA / Keyboard /Track ball
Optional for 10' or 15'
KVM side: 1 D-sub 15 pin proprietary KVM connector
Server side: 1 D-sub 15 pin VGA and 1 x USB connecors
Drawer Design:
High load-rating slide rail with angle bracket
extension up to 31.1" depth
Optional Extension bracket to 36" depth
Power adapter:
External 110/220VAC power adapter
Color:
Black
Operation Temperature:
0ºC to 50ºC
Weight:
40 lb
Safty:
FCC, CE
Dimension:
19"(W) x 23.62"(D) x 1.75"(H)
» Ordering Guide
KDS 6198:
1U, 19" 1280x1024/1152x900 TFT LCD, 8 ports USB KVM switch
101-keys SUN-keys keyboard 3-buttons track ball, Black color
» Options
CD-6U: 6' USB KVM cable
CD-10U: 10' USB KVM cable
CD-15U: 15' USB KVM cable
© Copyright 2005 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
