  • Page 1 MODEL 1827 TAILGATER COMBO Parts & Assembly North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com...
  • Page 2 Tailgater Combo | Parts & Assembly SAFE T Y ALERT KE Y Before proceeding, make certain that you read and understand the Read and follow all of the notices Owner’s Manual included with found throughout the manual. your griddle. Hazardous fire or explosion may result if instructions are ignored.
  • Page 3: Parts & Assembly

    Tailgater Combo | Parts & Assembly PARTS & ASSEMBLY ILLUSTRATED PARTS LIST 01. Body (1 piece) 02. Grill box (1 piece) & Grill grates 03. Griddle top (1 piece) (2 pieces) 04. Hood (1 piece) & Grill box clip 05. Flame tamper (1 piece) 06.
  • Page 4 Tailgater Combo | Parts & Assembly ASSEMBLY INSTRUCTIONS Please read all instructions thoroughly before proceeding. Make sure all the plastic packing material is removed before assembling Find a large, clean area to assemble your griddle. Please refer to the parts list and assembly diagrams as necessary.
  • Page 5 Tailgater Combo | Parts & Assembly WA R N I N G ST EP 0 2 The manufacturer has made every effort to eliminate any sharp Place griddle upright. Attach the two (2) control knbs by pushing them onto edges. However, you should the connections on the griddle body, screw on the ignition button, and place handle all components with care the griddle top on to the right side of the body.
  • Page 6 Tailgater Combo | Parts & Assembly STEP 05 Connect the hood to the grill box by lining up the back hinges. Secure the hinges by inserting one (1) spacing ring over the outside of the hinge holes. Then, push one (1) hinge pin through the holes in the hinge and spacing pin.
  • Page 7 Tailgater Combo | Parts & Assembly STEP 0 7 Insert the flame tamper and the two (2) grill grates into the grill box. STEP 0 8 Hang the grease cups on both sides of the unit directly below the grease runoff. STEP 0 9 Proceed to seasoning instructions (pg 18) in the Owner’s Manual.
  • Page 8 North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com...
  • Page 9 MODELO 1827 TAILGATER COMBO Piezas y ensamblaje North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com...
  • Page 10 Tailgater Combo | Piezas y montaje LL AVE DE ALERTA DE Antes de continuar, asegúrese de leer y comprender el Manual SEGURIDAD del propietario incluido con su plancha. Lea y siga todos los avisos que se encuentran en el manual. Se pueden producir incendios o explosiones peligrosas si se P E L I G R O...
  • Page 11: Pie Z As Y Ensambl Aje

    Tailgater Combo | Piezas y montaje PIE Z AS Y ENSAMBL AJE LISTA DE PIE Z AS ILUSTRADA 01. Cuerpo (1 pieza) 02. Caja de parrilla (1 pieza) y rejillas 03. Tapa de la plancha (1 pieza) de parrilla (2 piezas) 04.
  • Page 12: Instrucciones De Montaje

    Tailgater Combo | Piezas y montaje INSTRUCCIONES DE MONTAJE Lea atentamente todas las instrucciones antes de continuar. Asegúrese de retirar todo el material de embalaje de plástico antes de ensamblarlo Encuentre un área grande y limpia para ensamblar su plancha. Consulte la lista de piezas y los diagramas de ensamblaje según sea necesario.
  • Page 13 Tailgater Combo | Piezas y montaje A D V E R T E N C I A El fabricante ha hecho todo lo PA SO 0 2 posible para eliminar los bordes afilados. Sin embargo, debe Coloque la plancha en posición vertical. Fije los dos (2) nudos de control manejar todos los componentes empujándolos en las conexiones en el cuerpo de la plancha, atornille el botón con cuidado para evitar...
  • Page 14 Tailgater Combo | Piezas y montaje PA SO 05 Conecte la campana a la caja de la parrilla alineando las bisagras traseras. Asegure las bisagras insertando un (1) anillo de separación sobre el exte- rior de los agujeros de la bisagra. Luego, empuje un (1) pasador de bisagra a través de los agujeros en la bisagra y el pasador de separación.
  • Page 15 Tailgater Combo | Piezas y montaje PA SO 07 Inserte el pisón de la llama y las dos (2) rejillas en la caja de la parrilla. PA SO 08 Cuelgue las copas de grasa en ambos lados de la unidad directamente debajo del escurrimiento de grasa.
  • Page 16 North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com...
  • Page 17 MODÈLE 1827 TAILGATER COMBO Pièces et assemblage North Atlantic Imports LLC | 1073 West 1700 North Logan, UT 84321 | Blackstoneproducts.com...
  • Page 18 Tailgater Combo | Pièces et assemblage CLÉ D'ALERTE DE Avant de continuer, assurez-vous de lire et de comprendre le mode SÉCURITÉ d'emploi fourni avec votre gril. Lisez et suivez tous les conseils qui Le non-respect des instructions se trouvent dans ce manuel. peut provoquer un incendie ou une explosion.
  • Page 19: Pièces Et Assembl Age

    Tailgater Combo | Pièces et assemblage PIÈCES ET ASSEMBL AGE LISTE DES PIÈCES ILLUSTRÉES 01. Corps (1 pièce) 02. Boîte à griller (1 pièce) et grilles à 03. Plaque chauffante (1 pièce) griller (2 pièces) 04. Capot (1 pièce) & pince pour 05.
  • Page 20: Instructions De Montage

    Tailgater Combo | Pièces et assemblage INSTRUCTIONS DE MONTAGE Veuillez lire attentivement toutes les instructions avant de continuer. Assurez-vous que tout le matériel d’emballage en plastique est enlevé avant de procéder à l’assemblage. Trouvez une grande surface propre pour assembler votre gril. Veuillez vous référer à...
  • Page 21 Tailgater Combo | Pièces et assemblage AT T E N T I O N Le fabricant a tout mis en É TAPE 02 œuvre pour éliminer les bords tranchants. Cependant, vous Placez la plaque chauffante à la verticale. Fixez les deux (2) boutons de devez manipuler tous les commande en les poussant sur les raccords du corps de la plaque chauffante, éléments avec soin pour éviter...
  • Page 22 Tailgater Combo | Pièces et assemblage É TAPE 05 Connectez la hotte à la boîte du gril en alignant les charnières arrière. Fixez les charnières en insérant une (1) bague d’espacement sur l’extérieur des trous de charnière. Ensuite, poussez une (1) goupille de charnière à travers les trous de la charnière et la goupille d’espacement.
  • Page 23 Tailgater Combo | Pièces et assemblage É TAPE 0 7 Insérez l’inviolabilité de la flamme et les deux (2) grilles du gril dans la boîte du gril. É TAPE 0 8 Accrocher les bacs à graisse des deux côtés de l’appareil directement sous l’écoulement de graisse.
