Date: 11/2020 - Rev: 1.3
* The order code of the PC is specifi c to each specifi c confi guration defi ned by the Customer.
system-electronics.it
INDUSTRIAL PC
USER MANUAL
1. General characteristics..............................................................3
2. Technical specifi cations.............................................................3
3.2 LED on the front panel.............................................4
3.3 Touch-Screen.............................................................4
System.............................................................................. 5
3.6 Adjusting the display brightness........................... 6
3.7 Display..........................................................................6
3.8 Connectivity................................................................6
3.9 Memory and data storage...................................... 6
3.10 Watch-Dog................................................................7
3.11 Terminal auto power on...........................................7
3.12 Typical terminal consumption...............................6
4. Back connectors..........................................................................7
4.3 External connection diagram M12..........................8
5. Accessories: Desk bracket........................................................ 9
6. Waste Directive (WEEE and ROHS)....................................... 9
Sommario

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COPILOT and is the answer not in the manual?

Questions and answers

Related Manuals for SYSTEM Electronics COPILOT

Summary of Contents for SYSTEM Electronics COPILOT

  • Page 1: Table Of Contents

    COPILOT 15’’ Sommario 1. General characteristics..............3 2. Technical specifi cations.............3 3. Copilot 15” Mini-ITX: Description and operation....3 3.1 Power on and off ............3 3.2 LED on the front panel..........4 3.3 Touch-Screen.............4 3.4 Default se ings of touch parameters....4 3.5 Cleaning and Maintenance of the Touch Screen...
  • Page 2 Industrial PC - COPILOT 15" Mini-ITX Revision History Pages Rev. 1.0 Drafting Rev. 1.1 Added Chapter Accessories Rev. 1.2 Update Rev. 1.3 Added touch-screen cleaning This product meets the EMC protection re- quirements of Directive 2014/30 / EC (ex 89/336 / EEC) and subsequent amend- ments.

  • Page 3: General Characteristics

    Storage: -20°C /+60°C Thanks also to the new integrated Wireless solutions, Operating in standard version: 0°C/+50°C such as Wi-Fi, the COPILOT 15" Mini-ITX terminal can Operating in version with cooler: 0°C/-60°C operate as a supervisor of the equipment connected to the machine and communicate with remote devices, such as the 10.4"...

  • Page 4: Led On The Front Panel

    Industrial PC - COPILOT 15" Mini-ITX The COPILOT 15" Mini-ITX' PC does not normally require calibration procedures, as it is already optimized during production. If there is a need to optimize the calibration of the tou- ch-screen follow the procedure below.

  • Page 5: Cleaning And Maintenance Of The Touch Screen System

    Figura 3.5.1 Make a "Z" movement, evenly across the entire surfa- ce, after possibly positioning the Copilot horizontally to prevent droplets from falling down and remaining inside the frame. Figura 3.5.2...

  • Page 6: Adjusting The Display Brightness

    LThe Wireless solutions of the COPILOT allow maximum freedom and flexibility in use, allowing you to drive remote equipment. The COPILOT is proposed as a universal operator in- terface, for the possibility to communicate with the machine and receive only the necessary data, as well as the desired manuals and manage the updating of the equipment in an easy way.

  • Page 7: Memory And Data Storage

    Industrial PC - COPILOT 15" Mini-ITX 4. Back Connectors 3.9 Memory and data storage The COPILOT 15" Mini-ITX provides up to 16GB of 4.1 Examples of some available DDR3 RAM memory. A SATA HDD from 80GB up to 1TB can be installed.

  • Page 8: External Connection Diagram M12

    Industrial PC - COPILOT 15" Mini-ITX 4.3 Wiring diagram for exter- RS232 RS422 RS485 BITBUS nal M12 connectors 24V power supply M12 Female 5-pole A • 1 +24V • 2 +24V _ _ _ _ _ _ _ _ _ •...

  • Page 9: Accessories: Desk Bracket

    Industrial PC - COPILOT 15" Mini-ITX 5. Accessories: 6. Waste Directive (WEEE and ROHS) Desk support Information to users pursuant to art. 13 of Legislative Decree 25 July 2005, n.151 "Implementation of Directi- ves 2002/95/EC, 2002/96/EC and 2003/108/EC, relating to the reduction of the use of hazardous substances in electrical and electronic equipment, and waste disposal.
