1.4.2

Removing a SIMM

Follow these steps to remove a SIMM:
1.
Press the holding clips on both sides of the SIMM outward to
release it.
Figure 1-8
Removing a SIMM
2.
Move the SIMM to a 45 angle.
3.
Pull the SIMM out of the socket.
Always remove SIMMs from the socket
labeled SIMM-4, then SIMM-3, and so on.
System Board
1-13
