3.4

Removing the CPU Board Support Bar

1.
Remove the screw that secures the CPU board support bar.
2.
Firmly hold the support bar and push it toward the front for about an
inch. This releases the rear end of the support bar.
3.
After releasing the rear end of the bar, carefully detach the front end
from the hook that secures it to the housing frame.
IDT Housing
9
