1.
Align the CPU board golden fingers with the exclusive connector on the
system board. Refer to your system board user's guide for the location
of the connector.
2.
Carefully install the CPU board until it fits in place.
3.
Attach the front end of the CPU board support bar to the hook on the
housing frame.
4.
Align the support bar with the edge of the CPU board, then insert the
protruding tabs of the bar into the holes on the rear of the housing.
Do not forget to install the support bar. It helps
prevent damage to the CPU and the CPU board
during transport.
14
Installation Guide
