Port
6
Parallel port switch
7
Phone line jack (RJ-11) Phone line
8
Phone set jack (RJ-11)
9
FireWire jack (1394)
10 Network jack (RJ-45)
11 Microphone-in/
line-in jack
12 Speaker/
headphone-out jack
13 S-video jack
14 External monitor port
15 USB jack
16 DC-in jack
Note: You can only select either the 25-pin FDD port or the
25-pin parallel port. The two ports cannot be used
simultaneously. Set the parallel port switch to the FDD
icon if using a floppy disk drive. Set to the Printer icon
when using a printer.
4
Connects to...
Slide this switch to the icon of the desired
peripheral (external floppy drive or printer) to
use that peripheral device.
Telephone apparatus
Firewire-compliant device (if your computer
has a built-in FireWire jack)
Network cable (if your computer has a built-in
network jack)
External microphone or audio line-in device
External speakers or headphones
S-video display device (e.g., television set with
S-video capability)
External monitor or other compatible display
device
Universal Serial Bus device
AC adapter and power outlet
DockMate V Quick Reference
