Z3210 Wireless Adapter
Instruction Manual for Excel
Introduction
Z3210ʼs Excel
®
Direct Input function allows you to input measurement values directly into Excel in the
same way as a wireless keyboard. By attaching the Z3210 V2.10 or later to Z3210 compatible devices and
enabling the Excel
®
Direct Input (HID function), you can easily input data to existing Excel forms. Please
read this instruction manual and check whether input is possible to the device (PC or tablet) before use.
Operation check OS: Windows 10
Preparation
Before using this function, you need to enable the HID function of the Z3210 and configure the
Bluetooth
®
connection settings.
Keyboard layout settings and Excel settings are also required depending on your operating environment.
Please refer to Table 1 for the method of switching the HID function of the Z3210.
Keyboard layout settings are not required if the keyboard layout is equivalent to Japanese 109 keyboards
or US QWERTY (US101). Many countries, such as China, Korea, Taiwan and Middle East countries use a
US101 equivalent keyboards, and do not need to be set up, but it is necessary to be set up in France,
Germany, etc., because the keyboards are inequivalent to a US101 one.
Since the decimal point output is a period (.), not a comma (,), you may need to set Excel options
depending on a country.
Model
HID function ON/OFF switching methods
CM4001
1. Turn on the power while holding down
(V1.03 or
the Backlight key and [RANGE].
later) *1
2. Each press of
between ON and OFF.
3. Press
4. Automatically turns off.
CM4002
1. Turn on the power while holding down
CM4003
[HOLD]
ON/OFF.
2. Automatically turns off.
FT6031-50
1. Turn on the power while holding down
(V1.02 or
[COMP]
later) *2
HID ON/OFF.
2. Automatically turns off.
iOS 13, iPadOS 13 or later
Android™ 9 or later (except for some models)
Table 1. HID function ON/OFF methods
[MAX/MIN]
[HOLD]
to confirm.
and
[COMP]
to switch the HID
and
[0Ω ADJ]
to switch the
HIOKI Z3210A962-02
Direct Input (HID function)
®
HID function ON/OFF checking methods
1. Turn on the power while holding down
the Backlight key and [RANGE].
toggles
2. Press the Power key to turn off the
power.
1. Turn on the power while holding down
the
[HOLD]
2. Press the Power key to turn off the
power.
1. Turn on the power while holding down
the [3P/2P].
2. Press the Power key to turn off the
power.
1
and [MAX/MIN].

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z3210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hioki Z3210

  • Page 1 Z3210ʼs Excel ® Direct Input function allows you to input measurement values directly into Excel in the same way as a wireless keyboard. By attaching the Z3210 V2.10 or later to Z3210 compatible devices and enabling the Excel ® Direct Input (HID function), you can easily input data to existing Excel forms. Please read this instruction manual and check whether input is possible to the device (PC or tablet) before use.
  • Page 2 Turn on the power while holding down the [Fn] and [COMP]. [0Ω ADJ] After “vEr” is displayed, press The firmware version can be comfirmed when “v1.0x” ↔ “6031” is displayed Press the Power key to turn off the power. HIOKI Z3210A962-02...
  • Page 3 How to check the firmware version of Z3210 The HID switching function of the Z3210 is available in V2.10 or later. You can check the firmware version by following the steps below. If you wish to use the HID function with less than V2.10, please contact your distributor or our nearest sales office.
  • Page 4 [Change Layout].) (Or click 5. Choosing a New Keyboard Layout. (US QWERTY) The new layout is installed on Windows 10. After the installation is completed, you can switch the keyboard layout with the keyboard shortcut [Windows] + [Space]. HIOKI Z3210A962-02...
  • Page 5 Follow the procedure below to set up. 1. Select [Settings] [General] [Keyboard] on the device. 2. Turn off [Enable Caps Lock]. HIOKI Z3210A962-02...
  • Page 6: How To Use

    It is not necessary for the US, Japanese or some other operating systems with decimal point using a period. The decimal point output by Z3210 is a period (.). If the decimal point that is used by the operating system is a comma (,), do one of the following two methods.
  • Page 7: Troubleshooting

    GPS function (location information), please go to OS settings and enable the Use location. Z3210 is not found when pairing iOS with Z3210 for The paired instrument will be displayed differently. the first time. [Accessories] will be displayed when Z3210 is not paired.
  • Page 8 Settings screen). Close GENNECT Cross. Delete the measuring instrument from the Bluetooth settings of your device. Disable the HID function of Z3210. For details, please refer to the “Preparation” section of this manual. Cannot input with the software keyboard of the When the device is connected to the measuring connected device.
  • Page 9 Excel files. I want to use it in other applications other than Applications that do not have a special function Excel. assigned to [Tab] may be usable. Please check beforehand before use. Mar. 2021 Revised edition 2 Z3210A962-02 21-03H HIOKI Z3210A962-02...
