- Page 1 INSTRUCTION MANUAL DIGITAL CLAMP METER KEW SNAP SERIES KEW SNAP 2 0 0 2 Ｐ Ａ 2 0 0 2 R KYORITSU ELECTRICAL INSTRUMENTS WORKS， LTD. GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Table Of Contents
ENGLISH Contents １．Safety Warnings ……………………………………………………… 1 ２．Features ……………………………………………………………… 4 ３．Specifications ３−１ KEW SNAP 2002PA …………………………………………… 5 ３−２ KEW SNAP 2002R …………………………………………… 7 ４．Instrument Layout …………………………………………………… 10 ５．Preparation for Measurement ５−１ Battery Voltage Check ……………………………………… 11 ５−２ Checking Switch Setting and Operation …………………… 11 ６．Measurement ６−１ Current Measurement…………………………………………12 ６−２ Voltage Measurement ………………………………………... -
Page 3: １．Safety Warnings
１．Safety Warnings ○This instrument has been designed and tested according to IEC Publication 61010；Safety Requirements for Electronic Measuring Apparatus. This instruction manual contains warnings and safety rules which must be observed by the user to ensure safe operation of the instrument and to retain it in safe condition. Therefore, read through these operating instructions before starting using the instrument. - Page 4 ○ Following symbols are used on the instrument and in the instruction manual. Attention should be paid to each symbol to ensure your safety. Refer to the instructions in the manual. Indicates an instrument with double or reinforced insulation. Indicates that this instrument can clamp on bare conductors when measuring a voltage corresponding to the applicable Measurement category, which is marked next to this symbol.
- Page 5 CAUTION ●Always make sure to check the function selector switch is set to an appropriate position before starting measurement. ●Always make sure to insert the plug of each lead fully into the appropriate terminal on the instrument. ●Be sure to set the function selector switch to the "OFF" position after use.
-
Page 6: ２．Features
２．Features ●Tear-drop-shaped jaws for ease of use in crowded cable areas and other tight places. ●Accurate true-RMS reading of AC current or voltage with distorted waveform (KEW SNAP 2002R) ●Provides a wide measuring range from 0 up to 2000A. ●Terminal cover to avoid the use of an incorrect terminal. ●Measures current variation as short as 10 msec with peak-hold feature. -
Page 7: ３．Specifications ３−１ Kew Snap 2002Pa
３．Specifications ３−１ KEW SNAP 2002PA ●Measuring Ranges and Accuracy(at 23±5℃, relative humidity 45-75%) 〜 〜 AC Current 400Ａ， 2000Ａ Range Measuring Range Resolution Accuracy（Frequency Range） Maximum Measurement Time ±1.0％rdg±3dgt(50/60Hz） 0.1Ａ 400Ａ ０〜400.0Ａ ±2.0％rdg±3dgt(40〜１kHz) Continuous ０〜1000Ａ ±1.0％rdg±3dgt(50/60Hz） 2000Ａ 1000〜1500Ａ 15min １Ａ ±3.0％rdg±3dgt(40〜１kHz) 1500〜2000Ａ... - Page 8 ●Operating System Dual Integration ●Display Liquid crystal display with a maximum count of 4000 ●Low Battery Warning "BATT" symbol is displayed on the digital display. ●Overrange Indication "OL" is displayed where input exceeds the upper limit of a range ●Response Time Approx.
-
Page 9: ３−２ Kew Snap 2002R
３−２ KEW SNAP 2002R ●Measuring Ranges and Accuracy(at 23±5℃, relative humidity 45-75%) 〜 〜 AC Current 400Ａ， 2000Ａ (9 counts or less is corrected to 0) Range Measuring Range Resolution Accuracy（Frequency Range） Maximum Measurement Time ±1.5%rdg±3dgt（45〜65Hz） 0.1Ａ 400Ａ ０〜400.0Ａ Continuous ±2.5%rdg±3dgt（40〜1kHz） ０〜1000Ａ... - Page 10 ●Operating System Dual Integration ●Display Liquid crystal display with a maximum count of 4000 ●Low Battery Warning "BATT" symbol is displayed on the digital display. ●Overrange Indication "OL" is displayed where input exceeds the upper limit of a range ●Response Time Approx.
- Page 11 ― 9 ― GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 12: ４．Instrument Layout
４．Instrument Layout Transformer Jaw Barrier Jaw Trigger Function Switch Data Hold Switch Display Reset Switch Mode Switch Drop Prevention Strap Terminal Cover OUTPUT Terminal ︸ COM Terminal Test Leads Ｍー7107 Ｖ／Ω Terminal Recorder Output Plug Ｍー8102 ● ＬＣＤ INDICATOR DC Current AC Current Data Hold Mode Resistance Negative Potential Voltage Current Continuity Check Mode Battery Voltage Alert Peak Mode Measurement ― 10 ― GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com... -
Page 13: ５．Preparation For Measurement
５．Preparation for Measurement ５−１ Checking Battery Voltage ①Set the function selector switch to any position other than "OFF". ②When the display is clear without "BATT" showing, proceed to measurement. ③When the display blanks or "BATT" is indicated, replace the batteries according to section 8: battery replacement. NOTE ●... -
Page 14: ６．Measurement
６．Measurement ６−１ Current Measurement WARNING ●Do not make measurement on a circuit above 750V AC. This may cause shock hazard or damage to the instrument or equipment under test. ●Transformer jaw tips are designed not to short the circuit under test. If equipment under test has exposed conductive parts, however, extra precaution should be taken to minimize the possibility of shorting. - Page 15 ③Take the reading on the display. NOTE ● During current measurement, keep the transformer jaws fully closed. Otherwise, accurate measurement cannot be made. The maximum measurable conductor size is 54.5mm in diameter. ● When measuring a larger current, the transformer jaws may buzz. This is not a fault and does not affect the accuracy at all.
-
Page 16: ６−２ Voltage Measurement
６−２ Voltage Measurement WARNING ●Do not make measurement on a circuit above 750V AC or 1000V DC. This may cause shock hazard or damage to the instrument or equipment under test. ●Do not make measurement with the battery compartment cover removed. ●Keep your fingers and hands behind the barrier during measurement. Black test lead Red test lead ６−２−１ DC Voltage Measurement... -
Page 17: ６−３ Resistance Measurement
６−３ Resistance Measurement WARNING ●Before attempting to make measurement, make sure that the circuit under test is not live. The instrument is protected against a voltage up to 600V. ●Do not make measurement with the battery compartment cover removed. ●Keep your fingers and hands behind the barrier during measurement. Black test lead Red test lead... - Page 18 ６−３−２ Continuity Check ①Set the function selector switch to the "Ω/ " position. ②Slide the terminal cover to the left. Plug the red test lead into the V/Ω terminal and the black test lead into the COM terminal. ③Press the mode switch to set the instrument to the continuity check mode.
-
Page 19: ７．Notes On Functions ７−１ Data Hold
７．Notes on Functions ７−１ Data Hold This is a function used to freeze the measured value on the display. ①Press the data hold switch. The reading becomes frozen and the "H" symbol is shown on the display, indicating the instrument in the data hold mode. ②To exit the data hold mode, press the data hold switch again to release it. -
Page 20: ７−３ Output For Recorder
②To enable the sleep function, turn the function selector switch back to "OFF", then to any other position. NOTE ● The instrument consumes small amount of current in the sleep mode. When the instrument is not in use, make sure to set the function selector switch to "OFF". -
Page 21: ７−４ Mode Switching Function
［How to attach a pair of leads to the recorder output plug］ Attach one end of the leads to the recorder output plug observing correct polarity, then connect the other end to the recorder. DANGER Never apply voltage to the output terminal. ７−４ Mode Switching Function On a AC current ("〜400A" or "〜2000A") or the resistance(Ω/ range, press the mode switch to cycle through the measurement modes. -
Page 22: ８．Battery Replacement
８．Battery Replacement WARNING ●To avoid electric shock hazard, make sure to set the function selector switch to "OFF" and remove the test leads from the instrument before trying to replace batteries. CAUTION ●Do not mix new and old batteries. ●Make sure to install batteries in correct polarity as indicated in the battery compartment. -
Page 23: ９．Optional Accessories
９．Optional Accessories ＭＡＸ ● Multi-Tran MODEL 8008 extends the 100㎜ capability of KEW SNAP 2002PA or KEW SNAP 2002R, allowing measurement up to 3000A or on a large bus-bar or ＭＡＸ conductor. 150㎜ ①Set the function selector switch to "〜 400A" ②As shown in the figure below, clamp KEW SNAP 2002PA or KEW SNAP 2002R onto the pickup coil of MODEL... - Page 24 DISTRIBUTOR Kyoritsu reserves the rights to change specifications or designs described in this manual without notice and without obligations. 11―11 92―1579E GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
