- Page 1 English Trademarks VGA & 8514/A are registered trademarks of the IBM Corporation. Super VGA is a registered trademark of VESA. Edition A...
-
Page 2: Table Of Contents
English CONTENTS FCC warning ...E-1 DOC notice ...E-1 Safety precautions ...E-1 Packing contents ...E-2 Unpacking procedure ...E-2 Repacking ...E-2 Introduction ...E-2 Power saving ...E-2 Install the monitor ...E-3 Power cord ...E-3 User controls and indicators ...E-4 Using the on-screen menu ...E-5 Individual adjustment ...E-6 Troubleshooting...E-8 Servicing ...E-8... -
Page 3: Fcc Warning
EDERAL OMMUNICATIONS (FCC) W OMMISSION ARNING nstruction to Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Packing Contents
PACKING CONTENTS The package contains: • CRT monitor • AC power cord • User manual UNPACKING PROCEDURE REPACKING Save the origional box and all packing material for future shipping needs. * Packing materials and product are recyclable. INTRODUCTION This microprocessor-based, digital control 17” color monitor is a high performance and easy to use product. -
Page 5: Install The Monitor
INSTALL THE MONITOR • To connect the tilt/swivel base to the monitor, align hooks with the sockets on bottom side of the monitor, and gently push the base towards the front of the monitor. • The 15-pin D-shell signal connector on the signal cable will connect easily to the video adapter output on your personal computer. -
Page 6: User Controls And Indicators
USER CONTROLS AND INDICATORS a. Displays menu & exits menu b. Scrolls through menu to choose an icon for adjustment / Adjusts level of selected icon c. Confirms menu selection 1. Power LED 2. Power ON/OFF switch... - Page 7 USING THE ON-SCREEN DISPLAY 1) Menu screen-press the button to display the menu below and exit menus Select mark Press the button to move the selection mark to the desired location. CONTRAST The item presently CONTRAST being adjusted is V.SIZE shown.
-
Page 8: Individual Adjustment
INDIVIDUAL ADJUSTMENT CONTRAST adjustment Adjust the screen contrast to match your personal perference. Press the button to decrease contrast and press the button to increase it. Direct operation: You can access the CONTRAST adjustment screen by pressing the before entering the menu screen. - Page 9 COLOR selection The white of the image can be adjusted. 1) Use the button to select: (1)9300 (2)6500 K or (3)User color. 2) If the (3):the user’s color is selected, “2” appears in the lower right of the On-Screen Menu. Press the button to display the USER COLOR adjustment screen.
-
Page 10: Troubleshooting
TROUBLESHOOTING If your monitor fails to operate functionally, it may be possible to correct the problem by making simple checks as follows: Problem Check & Adjust Blank screen · Monitor power switch, (*NOTE) power cord, signal cable, or connector · PC power switch ·... -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS 1 7 " v i s u a l d i a g o n a l V i e w a b l e s c r e e n s i z e S c r e e n S i z e 1 5 . -
Page 12: Preset Modes
E-10 PRESET MODES Resolution Mode (H x V) 720 x 400 640 x 480 800 x 600 640 x 480 800 x 600 1024 x 768 800 x 600 H. Freq. V. Freq. Mode (KHz) (Hz) 31.4 31.4 37.9 43.3 46.8 48.3 53.6... -
Page 13: Power Input
EDERAL OMMUNICATIONS (FCC) W OMMISSION ARNING nstruction to Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 14 PACKING CONTENTS The package contains: • CRT monitor • AC power cord • User manual UNPACKING PROCEDURE REPACKING Save the origional box and all packing material for future shipping needs. * Packing materials and product are recyclable. INTRODUCTION This microprocessor-based, digital control 17” color monitor is a high performance and easy to use product.
- Page 15 INSTALL THE MONITOR • To connect the tilt/swivel base to the monitor, align hooks with the sockets on bottom side of the monitor, and gently push the base towards the front of the monitor. • The 15-pin D-shell signal connector on the signal cable will connect easily to the video adapter output on your personal computer.
- Page 16 USER CONTROLS AND INDICATORS a. Displays menu & exits menu b. Scrolls through menu to choose an icon for adjustment / Adjusts level of selected icon c. Confirms menu selection 1. Power LED 2. Power ON/OFF switch...
- Page 17 USING THE ON-SCREEN DISPLAY 1) Menu screen-press the button to display the menu below and exit menus Select mark Press the button to move the selection mark to the desired location. CONTRAST The item presently CONTRAST being adjusted is V.SIZE shown.
- Page 18 INDIVIDUAL ADJUSTMENT CONTRAST adjustment Adjust the screen contrast to match your personal perference. Press the button to decrease contrast and press the button to increase it. Direct operation: You can access the CONTRAST adjustment screen by pressing the before entering the menu screen.
- Page 19 COLOR selection The white of the image can be adjusted. 1) Use the button to select: (1)9300 (2)6500 K or (3)User color. 2) If the (3):the user’s color is selected, “2” appears in the lower right of the On-Screen Menu. Press the button to display the USER COLOR adjustment screen.
- Page 20 TROUBLESHOOTING If your monitor fails to operate functionally, it may be possible to correct the problem by making simple checks as follows: Problem Check & Adjust Blank screen · Monitor power switch, (*NOTE) power cord, signal cable, or connector · PC power switch ·...
- Page 21 TECHNICAL SPECIFICATIONS 1 7 " v i s u a l d i a g o n a l V i e w a b l e s c r e e n s i z e S c r e e n S i z e 1 5 .
- Page 22 E-10 PRESET MODES Resolution Mode (H x V) 720 x 400 640 x 480 800 x 600 640 x 480 800 x 600 1024 x 768 800 x 600 H. Freq. V. Freq. Mode (KHz) (Hz) 31.4 31.4 37.9 43.3 46.8 48.3 53.6...
