Mohu sail Instructions

INSTRUCTIONS
- Make sure there is another person present (on the ground)
while installing the antenna.
- DO NOT attempt to mount the antenna on a windy, rainy, or
snowy day.
1
2
If you have any di˜culties with the installation of your antenna, please contact Mohu®.
Si tiene alguna difcultad instalando su antena, por favor contacte a Mohu®.
support@gomohu.com
BOX INCLUDES
A
B
II 1.877.825.5572 II
IMPORTANT
If you intend to mount the antenna on a rooftop, make sure to
mount it at least 20 ft. away from any power lines or utility poles.
3
4
POWER OPTIONS:
www.gomohu.com
Connect one end of the 30 ft. Coaxial
Cable to the connector on the antenna
(see illustration below) and connect the
other end of the coaxial cable to the
power injector.
Excessive cable length may cause
reception loss.
Connect the coaxial cable from the power
injector to the ANT/IN connector on the
back of the TV.
The power injector must be powered in
order to function. Plug the power
injector's USB cable into an open USB
port on the back of the TV.
If the TV does not have a USB port, use
the included USB power adapter with any
standard 120V wall outlet.
Note: If using an RF
splitter, follow the RF
splitter installation
instructions on the
back of this page.
30 ft.
Coaxial Cable
OR
Continued
ANT/IN
