1.2 Motherboard Specifications

Model Name
Processor Support / System Bus
Core Logic
Memory
Expansion Slots
(follow SSI Location #)
Storage
Networking
Graphic
Audio
10 Chapter 1: Technical specifications
Total Slots
Capacity
Memory Type
Total PCI/PCI-X/PCI-E slots
Slot Location 1
Slot Location 2
Slot Location 3
Slot Location 4
Slot Location 5
Slot Location 6
Slot Location 7
SATA Controller
LAN
VGA
P9X79 WS/IPMI
1 x Socket LGA 2011
2nd Generation Intel Core i7 Proces-
sor for the LGA 2011 Socket
Intel Xeon® E5-1600 V2 processor
for the LGA 2011 Socket
Intel Xeon E5-2600 V2 processor for
the LGA 2011 Socket
Intel X79 Express Chipset
8 (4 channels)
Maximum up to 64GB
DDR3 2400 (O.C.) / 2133 (O.C.) /
1866 (O.C.) / 1600 / 1333 / 1066
MHz, ECC, Non-ECC, un-buffered
Memory
5
PCI-E x16 (x8 Gen3 link)
PCI-E x16 (x8 Gen3 link)
PCI-E x16 (x16 Gen3 link) (Auto
switch to x8 link if slot 2 is occupied)
--
PCI-E x16 (x8 Gen3 link)
PCI-E x16 (x16 Gen3 link) (Auto
switch to x8 link if slot 5 is occupied)
--
Intel X79 Express Chipset:
- 2 x SATA 6Gb/s ports
- 4 x SATA 3Gb/s ports (supports
software RAID 0, 1, 10
2 x Intel I210AT
1 x Management LAN
Aspeed AST2300 32MB
Realtek® ALC 1150 8-channel High
Definition Audio CODEC
- Supports 192kHz/ 24bit BD Lossless
Sound
- DTS Surround Sensation UltraPC II
- Supports Jack-Detection,
Multi-Streaming, and Front Panel
Jack-Retasking
- Optical S/PDIF Out port at back I/O
