In addition, the following code must be placed in the project XDC file to correctly configure the
MCS file.
# Bitstream Configuration
# ------------------------------------------------------------------------
set_property CONFIG_VOLTAGE 1.8
set_property BITSTREAM.CONFIG.CONFIGFALLBACK Enable
set_property BITSTREAM.GENERAL.COMPRESS TRUE
set_property CONFIG_MODE SPIx4
set_property BITSTREAM.CONFIG.SPI_BUSWIDTH 4
set_property BITSTREAM.CONFIG.CONFIGRATE 85.0
set_property BITSTREAM.CONFIG.EXTMASTERCCLK_EN disable [current_design]
set_property BITSTREAM.CONFIG.SPI_FALL_EDGE YES
set_property BITSTREAM.CONFIG.UNUSEDPIN Pullup
set_property BITSTREAM.CONFIG.SPI_32BIT_ADDR Yes
# ------------------------------------------------------------------------
Program the Alveo Card
After the MCS file is created, see the procedure in the "Programming the FPGA Device" chapter
in the Vivado Design Suite User Guide: Programming and Debugging (UG908) to connect to the
Alveo Data Center accelerator card using the hardware manager.
1. Select Add Configuration Device and select the mt25qu01g-spi-x1_x2_x4 part.
2. Right-click the target to select Program the Configuration Memory Device.
a. Select the MCS file target.
b. Select Configuration File Only.
c. Click OK.
3. After programming has completed, disconnect the card in the hardware manager, and
disconnect the USB cable from the Alveo accelerator card.
4. Perform a cold reboot on the host machine to complete the card update.
