Goalzero Nomad 3.5 Manual

Get to know your gear
Reflective nylon loops make the NOMAD 3.5
Getting Started
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Open and remove protective film from solar cells.
3. Position and angle towards the sun (see below).
4. Plug your device into one of the charging ports.
BEST
SOLAR PANEL
Mob: +91 9962534747, E-Mail: info@upbeattech.com, Web: www.upbeattech.com
UPBEAT TECHNOLOGIES
How to use your gear
USB output port
HANG IT Accepts any standard USB cable for charging USB devices.
Solar output port
easy to hang and find.
Charges the GOAL ZERO GUIDE 10, faster than USB.
CHARGE IT
NOMAD 3.5's highly efficient solar
cells deliver up to 3.5 watts
of power in a small package.
COLLECT IT
Monocrystalline cells deliver the most
power in the smallest area.
OKAY BAD
Technical Specs
Usage
Charges the following:
GOAL ZERO GUIDE 10
Cell phone, MP3 player
Not compatible with Smart Phones or large USB devices
Inputs
Solar panel
Outputs
USB port
Solar port (for Guide 10)
General
Weight (no pkg)
Dimensions (folded)
Backside
Dimensions (unfolded)
Warranty
Certifications
Optimal Operating Temp.
Comes With
12V car adapter
Approx. charge time:
6-8 hours
2-5 hours
Rated wattage: 3.5W
Cell type: monocrystalline
Open-circuit voltage: 6.5-7V
Converting eff.: 17-18%
Cell area: 0.0199 m
2
5V, 0.5A max (2.5W), linear regulated
6-6.5V, 0.5A max (3.0W), not regulated
0.5 lbs (0.22 kg)
7x5.5x1 in (17.7x13.9x2.5 cm)
14x7x0.5 in (33.5x17.7x1.2 cm)
12 months
FCC and CE
0-120ºF (-17-48ºC)
