SERVICE MANUAL
Ver 1.0 2002. 02
• SA-VE335 consists of the following models respectively.
Active Subwoofer
SA-WMS335
Front and Rear Speakers
SS-V335
Center Speaker
SS-CN335
SA-VE335
For the U.S. model
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION:
with 8 ohm loads, from 20 – 150 Hz; rated
100 watts per channel minimum RMS power,
with no more than 0.8% total harmonic
distortion from 250 milliwatts to rated
output.
SS-V335 (front and rear speakers)
Speaker system
Full range, magnetically
shielded
5.5 × 11 cm
Speaker units
×
(
in.), cone type
7/32
7/16
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity
Maximum input power: 100 watts
Sensitivity level
87 dB (1 W, 1 m)
Frequency range
90 Hz – 20,000 Hz
Approx. 70 × 152 × 126
Dimensions (w/h/d)
× 6 × 5 in.),
mm (2
7/8
including front grille
Mass
Approx. 830 g
(18 lb 5 oz) each
Sony Corporation
9-873-585-01
2002B0400-1
Home Audio Company
© 2002. 02
Published by Sony Engineering Corporation
SA-WMS335
SS-V335
SPECIFICATIONS
SS-CN335 (center speaker)
Full range × 2,
Speaker system
magnetically shielded
5.5 × 11 cm
Speaker units
(
7/32
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity
Maximum input power: 120 watts
Sensitivity level
89 dB (1 W, 1 m)
Frequency range
90 Hz – 20,000 Hz
Approx. 300 × 78 × 126
Dimensions (w/h/d)
mm (11
including front grille
Mass
Approx. 1600 g
(35 lb 4 oz)
SA-WMS335 (subwoofer)
Speaker system
Active subwoofer,
magnetically shielded
Speaker unit
Woofer: 20 cm (7
cone type
Enclosure type
Advanced SAW type
Reproduction frequency range
26 Hz – 200 Hz
Amplifier section
Continuous RMS power output
100 W (8 ohms, 20 Hz –
20 kHz, 0.8% THD)
SA-VE335/WMS335/
SS-CN335/V335
Canadian Model
SS-CN335
Inputs
LINE IN (input pin jack)
General
×
Power requirements
in.), cone type
7/16
North American model: 120 V AC, 60 Hz
European model:
Other models:
Power consumptions
Dimensions (w/h/d)
× 3
× 5 in.),
7/8
1/8
Mass
Supplied accessories
Foot pads (20)
Audio connecting cord (1)
in.),
7/8
Speaker connecting cords, 10 m (32 ft 9
Speaker connecting cords, 3.5 m (11 ft 6 in.) (3)
Design and specifications are subject to change
without notice.
MICRO SATELLITE SYSTEM
US Model
AEP Model
UK Model
E Model
220 – 230 V AC, 50/60 Hz
110 – 120 V/220 – 240 V
AC, 50/60 Hz
90 W
1 W (standby mode)
Approx. 230 × 392 × 464
mm
× 15
× 18
(9
in.),
1/8
1/2
3/8
including front grille
Approx. 13.2 kg
(29 lb 2 oz)
in.) (2)
3/4
1
