Appendix D: Spare Parts

Spare Parts List
Reference is made to the item numbers in drawing filenr. OMC150-3 and OMC-150-6
Order number Name
OMC-9169 Set Precision ball bearing
ball bearings Retaining ring
for speed or
Precision ball bearing
direction shaft
Retaining ring
Set of small 2 O-rings
mounting
2 O-rings
materials and
Plain washer
O-rings
Spring washer
Capped nut
OMC-9151 Dual Wiper Potentiometer
OMC-9156 Proximity switch
OMC-9166 Cup assembly for OMC-150 /
OMC-160
OMC-9155 Vane assembly
OMC-9150 Shaft for speed or direction head
Set of U-bolts 2 U-bolt
2 Plain washers
2 Nuts
Manual | OMC-150
Status: Final | Not confidential
Dimensions
10x19x7mm
DIN-471A, St.st. 10mm
8x22x9mm
DIN-471A, St.st. 8mm
small
42x2mm NBR70
M6 A2 DIN-125A
M6 A2 DIN-127
M6 A1 DIN-1587
SCP40-8266A
P&F SJ3,5N
St.st, 68mm pitch, M10
M10
M10 A4
Drawing
item no.
14
13
28
27
26
25
24
8
10
4
12
30
