- Page 1 “Results You Can Count On” Model 458-2SL Multi-Channel Local Loop Simulator 0315-0333 Rev. D Date of Publication: 02/27/06...
- Page 2 Loop Simulator. This compact unit is extremely easy to use and a perfect fit when only one or two-channel operation is required. The Model 458-2SL is ideally suited for testing DSL modems and other bandwidth-compliant telecom devices in a high- volume production line environment.
- Page 3 The above warranty is in lieu of all other warranties, expressed or implied, statutory or otherwise, including any implied warranty of merchantability or fitness for a particular purpose. TELEBYTE shall not be liable for any damages sustained by reseller or any other party arising from or relating to any equipment failure, including but not limited to consequential damages, nor shall TELEBYTE have any liability for delays in replacement or repair of equipment.
- Page 4 Equipment Returns Out of warranty equipment may be returned, prepaid, to the Greenlawn, N.Y. customer service facility. Return shipping charges will be billed to the customer. The repaired unit will have a 90-day warranty. In those cases where "no trouble" is found, a reduced charge will be billed to cover handling, testing, and packaging.
-
Page 5: Table Of Contents
Table of Contents 1.0 Introduction ........................1 Chassis/Control Module ..................... 1 Line Module Series ..................... 1 2.0 Specifications ........................2 3.0 Connections ........................3 4.0 RS-232 Control ......................... 4 Connections ........................ 4 User Command Interface ................... 5 Serial RS-232 Mode Command List ................5 5.0 IEEE Controls ........................ -
Page 6: Introduction
458-2SL gives manufacturers the ability to test multiple devices using a single, rack-mounted wireline simulator unit. The Model 458-2SL can be configured to support a maximum of two Line Modules. Each line may be controlled through an RS-232 or IEEE-488 interface or the rotary encoders on the front panel. -
Page 7: Specifications
Translate CR to CR + LF; baud rate: 300 to 19200; commands use terminating character (carriage return); 8 Data bits; 1 stop bit. Specifications are subject to change without notice. Made in the USA. Page 2 Model 458-2SL User Manual - Rev. D... -
Page 8: Connections
I/O cables should be limited to 3 M or less. Check that the connections made to each port are completely isolated from each other (floating or transformer coupled). GREEN Figure 1: RJ-45 Configuration Page 3 Model 458-2SL User Manual - Rev. D... -
Page 9: Rs-232 Control
CONNECTOR DB9 Figure 2 DB-9 for RS-232 Control Pin 2 on the Model 458-2SL connects to the RECEIVED DATA pin in the Communications Port Connector on the PC or controller. Pin 3 on the Model 458-2SL connects to the TRANSMIT DATA pin in the Communications Port Connector on the PC or controller. -
Page 10: User Command Interface
Ground Common Ground + Voltage Out + Voltage Out The remaining pins are not connected to the Model 458-2SL. User Command Interface ASCII command set compliant with IEEE 488.2 and in Hex ASCII two-character bytes per 488 bus data byte. - Page 11 (used in 458-2SL only) Enable manual control enable manual setting of lengths or configuration (used in 458-2SL only) Identify model no. and rev. read model no. and software revision code Page 6 Model 458-2SL User Manual - Rev. D...
- Page 12 RS232 command list cs:BR Configure serial where BR = 300, 600, 1200, 2400, 4800, 9600 or 19200 cp:ADD Configure 488 where ADD = 1, 2, ... 29, 30 (No leading zeroes used) Page 7 Model 458-2SL User Manual - Rev. D...
-
Page 13: Ieee Controls
Bus controller. User Command Interface The Model 458-2SL is intended to be operated from an IEEE Controller such as a PC equipped with an IEEE interface board. The set up of your computer and IEEE controller board may be different depending on the manufacturer of your equipment. Follow the set up instructions supplied with your equipment. -
Page 14: Ieee Mode Command List
:readcard:length:aa-bb Read length of cards aa-bb read length of cards in range from aa to bb :readcard:length:aa+bb Read length of cards aa+bb read joined length of cards aa and bb Page 9 Model 458-2SL User Manual - Rev. D... - Page 15 *idn? Identify model no. and rev. read model no. and software revision code *esr? Event Status Register read read IEEE esr *sre? Status Request Enable read read IEEE sre Page 10 Model 458-2SL User Manual - Rev. D...
- Page 16 Enables Event Status Bits as defined by the numerical value of the bits following the command. *ESE? Used to read the Enabling Bits in the Event Status Enable Register. *ESR? Reads the Event Status Enable Register. Page 11 Model 458-2SL User Manual - Rev. D...
- Page 17 Enable Event Status Bit (ESB) MSS this bit is always enabled Not Supported Event Status Enable Register Value Operation Operation Complete Not Supported Query Error Not Supported Execution Error Command Error Not Supported Power On Page 12 Model 458-2SL User Manual - Rev. D...
-
Page 18: Appendix A Line Module Theory Of Operation
G represents the dielectric losses in the insulation of the wire. These losses increase with frequency, consequently, G will decrease at higher frequencies. The Telebyte Model 458-LM20 Line Module represents this equivalent circuit using a finite number of networks in series. These networks have been synthesized using interactive computer design techniques. - Page 19 That is, the losses in dB at each frequency are directly additive (within the tolerances of each line module). Network Network Network N Sections Figure 5: Simulator Block Diagram Page 14 Model 458-2SL User Manual - Rev. D...
