Telebyte 458-LM-E1-36-TP100 Reference Manual

Multi-standard local loop simulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
"Results You Can Count On"
Model 458-LM-E1-36-TP100
Rev.-
Date of Publication:02/25/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 458-LM-E1-36-TP100 and is the answer not in the manual?

Questions and answers

Related Manuals for Telebyte 458-LM-E1-36-TP100

Summary of Contents for Telebyte 458-LM-E1-36-TP100

  • Page 1 “Results You Can Count On” Model 458-LM-E1-36-TP100 Rev.- Date of Publication:02/25/2019...
  • Page 2 Customer Support Thank you for your purchase of the Telebyte Model 458-LM-E1-36-TP100 Multi-Standard Local Loop Simulator. This one-channel product simulates TP100 as specified in ETSI TS 101 270-1 and G.992.5 Annex M. Contact Information: Telephone E-mail/Internet General: 631-423-3232 support@telebytebroadband.com Technical support: 800-835-3298 sales@telebytebroadband.com...
  • Page 3 TELEBYTE, INC. warrants its broadband simulation equipment to be free from defects in material and workmanship, under normal and proper use and in its unmodified condition, for 12-months, starting on the date it is delivered for use. TELEBYTE’S sole obligation under this warranty shall be to furnish parts and labor for the repair or replacement of products found by TELEBYTE to be defective in material or workmanship during the warranty period.
  • Page 4 Equipment Returns Out of warranty equipment may be returned, prepaid, to the Hauppauge, N.Y. customer service facility. Return shipping charges will be billed to the customer. The repaired unit will have a 90-day warranty. In those cases where "no trouble" is found, a reduced charge will be billed to cover handling, testing, and packaging.

  • Page 5: Table Of Contents

    Table of Contents 1.0 Introduction ..........................1-1 2.0 Specifications ..........................2-1 2.1 458-LM-E1-30-TP100 ........................2-1 2.2 458-3SLB ............................. 2-1 2.3 458-CC-16/458-CM ........................2-2 3.0 Control ............................3-1 3.1 Remote Commands ........................3-1 3.1.1 RS-232 (Serial Port) Remote Commands ................. 3-1 Graphical User Interface ......................

  • Page 6: Introduction

    1.0 Introduction The Model 458-LM-E1-36-TP100 Multi-Standard Local Loop Simulator is the ideal solution for ADSL, ADSL2, ADSL2+, and VDSL2 (including Profile 35b) chip/modem/DSLAM testing out to 9,000 m in very small increments. This powerful local loop simulator is plugged into our Model 458-3SLB (3-Slot) or 458-CC-16 (16 Slot) chassis where settings are controlled by a convenient keypad located on the front, RS-232, Ethernet or IEEE-488(GPIB).

  • Page 7: Specifications

    2.0 Specifications 2.1 458-LM-E1-36-TP100 Product Specifications • Simulation Accurately simulates attenuation and impedance • Full bidirectional operation at all specified frequencies • TP100 as specified in ETSI TS 101 270-1 & G.992.5 Annex M Bandwidth DC to 36 MHz Attenuation Accuracy...

  • Page 8: 458-Cc-16/458-Cm

    Specifications are subject to change without notice. Made in USA. ➢ Detailed information about the operation of the 458-3SLB and 458-CC-16/458-CM can be found in the reference manuals for those products. Only information specific to the 458-LM- E1-36-TP100 is provided in this manual. Model 458-LM-E1-36-TP100 Page 2-2...

  • Page 9: Control

    3.0 Control The Model 458-LM-E1-36-TP100 can be controlled three ways: via RS-232 and IEEE488 Remote Commands, our 458 Universal Graphical User Interface or the LCD display and buttons on the front panel of our 458-3SLB or 458-CM. 3.1 Remote Commands Please refer to the manuals for the 458-3SLB or 458-CC-16/458-CM for remote commands common to many line modules, including the 458-LM-E1-36-TP100.

  • Page 10: Graphical User Interface

    M = module (slot) number 01 – 16 (458-CM) or 01-03 (458-3SLB) Example: RL:02 = Read length of module in slot 02. Graphical User Interface ➢ Refer to the 458 Universal GUI Reference Manual for more information. Model 458-LM-E1-36-TP100 Multi-Standard Local Loop Simulator Page 3 -2...

  • Page 11: Lcd Display/Front Panel

    Step Three – Select Noise Levels • Use the UP arrow button to select the CO or CPE noise. • Adjust the noise level using the LEFT and RIGHT arrow buttons. Model 458-LM-E1-36-TP100 Multi-Standard Local Loop Simulator Page 3 -3...
