- Page 1 “Results You Can Count On” Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 Including Bridged Tap Rev A Date of Publication: 03/05/2019...
- Page 2 Customer Support Thank you for your purchase of the Telebyte Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 Including Bridged Tap. This one-channel product simulates 26 & 24 AWG PIC as specified in ANSI T1.417. Contact Information: Telephone E-mail/Internet General: 631-423-3232 support@telebytebroadband.com...
- Page 3 TELEBYTE, INC. warrants its broadband simulation equipment to be free from defects in material and workmanship, under normal and proper use and in its unmodified condition, for 12-months, starting on the date it is delivered for use. TELEBYTE’S sole obligation under this warranty shall be to furnish parts and labor for the repair or replacement of products found by TELEBYTE to be defective in material or workmanship during the warranty period.
- Page 4 Equipment Returns Out of warranty equipment may be returned, prepaid, to the Hauppauge, N.Y. customer service facility. Return shipping charges will be billed to the customer. The repaired unit will have a 90-day warranty. In those cases where "no trouble" is found, a reduced charge will be billed to cover handling, testing, and packaging.
-
Page 5: Table Of Contents
Table of Contents 1.0 Introduction ..........................1-1 2.0 Specifications ..........................2-1 2.1 458-LM-A1-30-TR114 ........................2-1 2.2 458-3SLB ............................. 2-1 2.3 458-CC-16/458-CM ........................2-2 3.0 Control ............................3-1 3.1.1 RS-232 (Serial Port) Remote Commands ................. 3-1 3.1.2 IEEE 488 (GPIB) Remote Commands ..................3-2 Graphical User Interface ...................... -
Page 6: Introduction
(16 Slot) chassis where settings are controlled by a convenient keypad located on the front, RS-232, Ethernet or IEEE-488(GPIB). The modular design of Telebyte’s products allows the 458-LM-A1-30-TR114 to be combined with other line modules for a wide variety of test configurations. -
Page 7: Specifications
> 90 dB Impedance Accuracy Typically +/- 10% 20 kHz to 30 MHz Maximum Voltage Tip – Ring 200 V Maximum Current 130 mA 2 RJ-45’s on front Connectors Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 including Bridged Tap Page 2-2... -
Page 8: 458-3Slb
➢ Detailed information about the operation of the 458-3SLB and 458-CC-16/458-CM can be found in the reference manuals for those products. Only information specific to the 458-LM- A1-30-TR114 is provided in this manual. Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 including Bridged Tap Page 2-3... -
Page 9: Control
3.0 Control The Model 458-LM-A1-30-TR114 can be controlled three ways: via RS-232 and IEEE488 Remote Commands, our GUI interface or the LCD display on the front panel of our 458-3SLx or 458-CM. 3.1 Remote Commands 3.1.1 RS-232 (Serial Port) Remote Commands... -
Page 10: Ieee 488 (Gpib) Remote Commands
Set bridge tap length of module 02 to 100 feet 3.1.2 IEEE 488 (GPIB) Remote Commands 26 AWG Section Set Length SETCARD:LENGTH:02:24025,N Read Length RL:M READCARD:LENGTH:M SETCARD:LENGTH:02:BT:100 Read bridge tap length command RL:M:BT READCARD:LENGTH:M:BT Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 Including Bridged Tap Page 3-2... -
Page 11: Graphical User Interface
• Use UP and DOWN arrows to select the slot and either the Bridged Tap or Straight Loop mode. • Select the length for the current slot/mode using LEFT or RIGHT arrow buttons. Model 458-LM-A1-30-TR114 Local Loop Simulator for TR-114 Including Bridged Tap Page 3-3...
