F.C - 6/5/2015
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Call Toll-Free 1-800-267-1739
or visit www.dhpfurniture.com
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
5530096
Metal Bunk Bed
Full Full
Lot Number
B34553009601-10125-M
Black
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DHP 5530096
Summary of Contents for DHP 5530096
- Page 1 5530096 Metal Bunk Bed Full Full Black Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge. Call Toll-Free 1-800-267-1739 or visit www.dhpfurniture.com...
- Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to the repair or replacement of defective carpet, or use a piece of the cardboard packaging to protect your floor and product.
- Page 3 B34 553009601...
- Page 4 Parts Replacement Parts, Call 1-800-267-1739 All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that you have all the parts needed for the assembly. Post 01 Slat Spacer 01 Post 02...
- Page 5 Hardware Pack Hardware Pack #: T 5530096-00 1/4" 5/16"X 3/4" 1/4" X 3/4" X 16 X 32 4 mm 1/4"X 2 3/16" Hardware Note: Please do not completely tighten all the hardware, until the entire assembly is complete, unless indicated otherwise in the step-by-step instructions.
- Page 6 Step 1 Attach (I) to (A,B) with BOLT 2 . Please hand tighten the bolts of Part (I), in order to easily assemble Parts (Z/T) in Step B34 553009601...
- Page 7 Step 2 2.1 Slide (Z) into (A) and then attach (Z) to (I) with BOLT 2; 2.2 Attach (T) to (A & B) with BOLT 2; 2.3 Attach (Z) to (T) with Bolt 1. Repeat Step 1 & 2, to complete the 2nd assembly.
- Page 8 Step 3 Attach (E) X 2 to (A & B) with BOLT 2 and WASHER 4. B34 553009601...
- Page 9 Step 4 Please Note: Wide side of the slot should be facing up ! 4.1 Attach (X) to (I) with BOLT 2; Attach (X) to (T) with BOLT 2; 4.2 Attach (J) x 4 to (A & B) with BOLT 3. B34 553009601...
- Page 10 Step 5 5.1 Slide PART (P) into the slots in PART (J) as illustrated. 5.2 Lock (P) into place with (Y) as illustrated. B34 553009601...
- Page 11 Step 6 6.1 Press (W) onto (P) as illustrated 6.2/6.3 Press (Q) onto (W) and alternate PART (Q) left and right as illustrated in 6.3. For better performance Parts (Q) & (W) should be equally spaced out, approximately 17.5 inches or 445mm from the side of the bed, as illustrated.
- Page 12 Helpful Hints Helpful Hints Weight Limit: 300 Lbs / 136 Kgs for upper bed 450 Lbs / 204 Kgs for lower bed lifting and carrying the unit to it's new location. reassembled to move. End Cap 01 T392540 They are illustrated on this page and available for replacement.
- Page 13 WARNINGS for Bunk Bed against the wall to prevent entrapment between the bed and wall. and jump ropes. B34 553009601...
- Page 14 Online @ www.dhpfurniture.com Nota: El producto debe ser registrado dentro del mismo cuatrimestre en que se realiza la compra. Visite www.dhpfurniture.com/eng/register para mas detalles DHP / 410E, First Street South, Wright City MO 63390, USA acerca de este concurso. Attention: Consumer Service.
- Page 15 Lea antes de comenzar a ensamblar Partes Piezas de reemplazo, llame 1-800-267-1739 utilizado su producto. Todo se incluye en 1 caja grande! (sin embargo es recomendable contar con ayuda adicional). Tiempo estimado de ensamble es 1.5 horas. Hay 1 caja(s) interna(s) que incluyen los componentes necesarios para completar este ensamblaje.
- Page 16 Instrucciones Paso 1 del extremo de la litera y en el carton. Una la parte (I) en (A,B) con TORNILLOS (2). Por favor dedo apretar los tornillos de la pieza (I) hasta el siguiente paso con el Paso 2. recomendado, o ambos, para ayudar a prevenir la probabilidad de quedar atrapado o de caidas.
- Page 17 Enregistrez votre produit pour savoir le prix du semestre! Comment s'inscrire: Scannez le code QR ou visitez-nous au www.dhpfurniture.com/eng/registrer Suivez-nous sur: au Canada. www.facebook.com/DorelHomeProducts www.twitter.com/DHPfurniture www.pinterest.com/dhpfurniture les concours et les promotions des informations DHP. de l'Est Remarque: Attention: Consumer Service. concours. B34553009601-10125-M...
- Page 18 Avant de commencer l'assemblage 1-800-267-1739 2 (cependant il vaut de 2 heures. l'assemblage. l'assmeblage. lors de l'assemblage. (A) POTEAU 01: T917570 (B) POTEAU 02: T917580 (E) GARDE-CORPS: T917590 Pr caution (X) ENTRETOISE CENTRALE: T917630 (I) FIN GARDE-CORPS 01: T917600 commercial. (T) FIN GARDE-CORPS 02: T917620 (Q) ENTRETOISE LATTE 01: T919490 enfants.
- Page 19 Instructions Advertissement DU LIT SUPERPOSE ET SUR LA BOITE. NI DE SOMMIER. avec le boulon (2) avec le boulon (2) avec le boulon (1) . DOUBLE STANDARD. POUR LE LIT DU HAUT, UTILISEZ UNIQUEMENT UN MATELAS DE 74 - 75 POUCES DE LONG PAR 53 1/2 - 54 1/2 POUCES DE LARGE.
