DHP 5512098 User Manual

Junior loft with storage steps white / pink
Hide thumbs Also See for 5512098:

Advertisement

Available languages

Available languages

Quick Links

Download this manual See also: User Manual
Weight Limits:200 Lb / 92 Kg
WARNING
WARNING FOR YOUNG CHILDREN: This product contains small components. Please ensure that they are kept away from small children. Children under the age of 6,
●
small infants and babies must not sleep on this bunk bed for safety reasons.
This product is designed for home use and not intended for commercial use.
●
Recommended # of people needed for assembly: 2 (however it is always better to have an extra hand). Estimated assembly time is 2 hour.
●
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
●
X.P. - 11/22/2013
Junior Loft with Storage Steps
0
29986 55121
4
STOP
5512098
DO NOT RETURN PRODUCT TO THE
STORE
If a part is missing or damaged, call our
toll-free customer service line. We will
gladly ship your replacement parts FREE
of charge:
1-800-267-1739
or access our website:
www.dhpfurniture.com
Date of Purchase
___ / ___ / ___
Lot Number
_________
B34551209801 - 10125 - M
White / Pink

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5512098 and is the answer not in the manual?

Questions and answers

Related Manuals for DHP 5512098

Summary of Contents for DHP 5512098

  • Page 1 5512098 Junior Loft with Storage Steps White / Pink 29986 55121 Weight Limits:200 Lb / 92 Kg DO NOT RETURN PRODUCT TO THE STORE STOP If a part is missing or damaged, call our toll-free customer service line. We will...

  • Page 2: Helpful Hints

    Warranty Information DHP warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to the repair or replacement of defective parts and no assembly labor is included.
  • Page 3 PARTS T910940 T914550 T910920 T921400 T921410 T921420 T921430 T921460 T917030 T921450 T910980 T914530 T910960 x 22 T914540 T914580 T914510 3 /32 B34551209801...
  • Page 4 PARTS T914610 T914660 T914650 T921470 T914620 T921480 T914640 T914630 T914820 T914830 T391660 T201050 T391650 X 44 X 21 4 /32 B34551209801...
  • Page 5 PARTS T914670 T914720 T914680 T914760 T914770 T914690 T914730 T914780 T914700 T914740 T914750 T914710 T914790 T914810 T914800 T300410 5 /32 B34551209801...
  • Page 6 PARTS BLISTER PACK T5512098-00-1/2 ST4.2 X 10mm 1/4" X 5/8" 1/4" X 3/4" 5/16" X 3/4" X 38 1/4" X 7/8" 1/4" X 1 1/4" X 10 1/4" X 2 3/16" 1/4" X 2 3/4" T5512098-00-2/2 ST4.2 X 12mm X 12 X 28 1/4"...
  • Page 7 Attach (I) & (T) to (C) & (D) with finger tighten BOLTS (5); Set (M) to (C & D). 7 /32 B34551209801...
  • Page 8 Attach (U) to (A) & (S), then set (L) to (A) & (S); Fix them in place with BOLTS (5) X 5. Attach (H) to (A),(B) & (S) using (P) X 3 with BOLTS (1); Attach (F) to (A) & (B) with BOLTS (5). 8 /32 B34551209801...
  • Page 9 Attach (G) to (A, B, C & D) with BOLTS (6). Attach (E) & (J) to (A, B, C & D) with BOLTS (5); Then fix (E) to (G) with BOLTS (2). X 11 9 /32 B34551209801...
  • Page 10 Attach the (O) to (G); Lock (O) in place with (Y) X 44. Attach the (Q) in the middle as shown. 10 /32 B34551209801...
  • Page 11 Attach (W) to (B) & (D1) with BOLTS (5) X 2; Attach (V) to (B & D1) with BOLTS (2). Set (X) into (B & D1); Then fix with BOLTS (5) X 3. 11 /32 B34551209801...
  • Page 12 Set (Z) to (K) with SCREW (8); Attach (Z) & (P) to (X) with BOLT (1); Attach (D2) to (D1 & K) with BOLTS (5) then attach (E2) to (D1 & K) with BOLTS (5). 12 /32 B34551209801...
  • Page 13 For the following steps you may need a SCREWDRIVER! Screw (11) onto (A1) & (F1); Attach (A1) & (F1) to (I1) then fasten by turning CAM (13) clockwise as far as possible. 13 /32 B34551209801...
  • Page 14 Screw (11) onto (B2); Attach the subassembly from previous step to (B2) then fasten by turning CAM (13) clockwise as far as possible. 14 /32 B34551209801...
  • Page 15 Attach (N) to (I2) with SREWS (7) then attach (N) to (F1) with SCREWS (7). NOTE: Please ensure a clearance between (I2) and (B2) to avoid scratching between the two parts. X 12 15 /32 B34551209801...
  • Page 16 Attach (C1) to (B2) with BOLTS (4); Then place the subassembly to the bed frame as shown. 10.2 10.1 16 /32 B34551209801...
  • Page 17 Disassemble the BOLT (1) for the (S) as shown in the zoom view. Attach (R) to (H & F) with BOLT (1); Fasten (B2) to (F & D2) with BOLTS (3); Attach (B1) to (Z) with BOLT (14) then to (D2) with BOLT (1). 11.1 11.2 17 /32...
  • Page 18 Attach (C1) to (A2) with BOLTS (4); Attach (K1) to (C1) with BOLTS (3). Place the subassembly into place as shown then fasten it to (B & D1) with BOLTS (2) and to (B1 & R) with BOLTS (3). 12.1 12.2 12.4 12.3...
  • Page 19 Screw (11) into (F2) & (C2); Insert (12) on both side of (F3). Attach (F3) & (K2) to (F2) & (C2); Fasten by turning CAM (13) clockwise as far as possible. 13.2 13.1 13.3 19 /32 B34551209801...
  • Page 20 Screw (11) into (J1); Attach the subassembly from previous step to (J1); Fasten by turing CAM (13) clockwise as far as possible. 14.1 14.2 14.3 20 /32 B34551209801...
  • Page 21 Screw (11) into (E1) then stick PAD (9) on (E1) as shown below. Attach (E1) to the subassembly from previous step; Fasten by turning CAMS (13) clockwise as far as possible. 15.1 15.4 15.3 15.2 21 /32 B34551209801...
  • Page 22 Attach (X1) to (J1) with BOLTS (4); Turn the drawer over then place it to place as shown below. Once assembly is complete, please make sure all hardware is tightened. 16.1 16.2 22 /32 B34551209801...
  • Page 23 T919380 T921500 T921490 NOTE: (Y1), (V1) & (Z1) have been pre-assembled on (A/B/C/D/D1/K), (E2) & (X1). They are available for replacement. 23 /32 B34551209801...
  • Page 24 PERIODICALLY CHECK AND ENSURE THAT THE GUARDRAIL, LADDER AND OTHER COMPONENTS ARE IN THEIR PROPER POSITION, FREE FROM DAMAGE, AND THAT ALL CONNECTORS ARE TIGHT. REPLACEMENT PARTS, INCLUDING ADDITIONAL GUARDRAILS, MAY BE OBTAINED FROM ANY OF OUR (DHP) DEALERS. DO NOT ALLOW HORSEPLAY ON OR UNDER THE BED AND PROHIBIT JUMPING ON THE BED.
  • Page 25 B34551209801 Límites Peso: 200Lbs / 92Kgs ALTO NO REGRESE ESTE PRODUCTO A LA TIENDA La tienda no tiene las piezas. Si faltan partes o las partes están dañadas llame gratis al servicio del cliente. Con gusto cambiaremos las partes sin cobro. Nesacita piezas o asistancia? Llame al 1-800-267-1739 O visite nuestra página internet www.dhpfurniture.com Para un servicio más rápido y confiable por favor tenga este manual en mano.
  • Page 26 PÁGINA 14 Atornille (11) sobre (B2); coloque la parte pre-ensamblada en el paso anterior enn (B2) y apriete girando los CAM(13) hacia la derecha lo más posible. PÁGINA 15 Una (N) en (I2) con TORNILLOS (7) y después una (N) en (F1) con TORNILLOS (7). NOTA: Por favor deje una separación entre (I2) y (B2) para evitar rayaduras entre ambas partes.
  • Page 27 COMPRUEBE Y ASEGÚRESE PERIÓDICAMENTE DE QUE LA BARANDILLA, LA ESCALERA Y OTROS COMPONENTES ESTÉN EN SU POSICIÓN APROPIADA, LIBRE DE DAÑO, Y DE QUE TODOS LOS CONECTADORES ESTÉN APRETADOS. r PIEZAS DE REEMPLAZO, INCLUYENDO BARANDALES DE PROTECCIÓN ADICIONALES, PUEDEN SERADQUIRIDAS EN CUALQUIERA DE NUESTROS DISTRIBUIDORES DHP. r NO PERMITA JUGAR EN O DEBAJO DE LA CAMA Y PROHÍBA SALTAR EN LA CAMA.

  • Page 28: Consejos Útiles

    Información de Garantía DHP garantiza que este producto está libre de defectos materiales y de mano de obra aceptando corregir cualquier defecto. Esta garantía es válida por un año a partir de la fecha de compra original de este artículo.
  • Page 29 B34551209801 Limites de poids: 200 Lbs / 92 Kgs ATTENTION NE RETOURNEZ PAS LE PRODUIT AU MAGASIN Les magasins individuels ne gardent pas de pièces. Si une pièce est manquante ou endommagée, appelez notre ligne sans frais du Service à la Clientèle. Nous vous expédierons avec plaisir vos pièces de remplacement GRATUITEMENT.
  • Page 30 PAGE 14 Visser (11) dans (B2); Attacher le sous-ensemble de l'étape précédente sur (B2), puis fixer-les en vissant cam (13) dans le sens horaire le plus loin possible. PAGE 15 Installer (N) à (I2) avec vis (7) puis installer (N) sur (F1) avec vis (7). REMARQUE: S'il vous plaît assurer un dégagement entre (I2) et (B2) pour éviter le grattement entre les deux pièces.
  • Page 31 ENDOMMAGÉES ET QUE TOUS LES BOULONS ET ÉCROUS SOIENT BIEN SERRÉS. LES PIEÈCES DE RECHANGE, Y COMPRIS GARDE-CORP SUPPLEMENTAIRE, PEUT ETRE OBTENIR A PARTIR DE L'UN DE NOS (DHP) CONCESSIONNAIRES. NE JOUEZ PAS SUR OU SOUS LE LIT ET NE SAUTEZ PAS SUR LE LIT.

  • Page 32: Informations Sur La Garantie

    Informations sur la garantie DHP garantit que ce produit est exempt de tout vice de matériau et de fabrication et s'engage à remédier à un tel défaut. Cette garantie couvre un an à compter de la date d'achat originale. Cela se limite uniquement à la réparation ou au remplacement des pièces défectueuses. Aucun travail de montage n'est inclus.
