X20(c)SC2212
Model number
Switching voltage
Total nominal current
Operating conditions
Mounting orientation
Horizontal
Vertical
Installation elevation above sea level
Degree of protection per EN 60529
Ambient conditions
Temperature
Operation
Horizontal mounting orientation
Vertical mounting orientation
Derating
Storage
Transport
Relative humidity
Operation
Storage
Transport
Mechanical properties
Note
Spacing
1) The related danger warnings in the technical data sheet must also be observed.
2) The protective function is provided for max. 30 minutes for a continuous short circuit.
3) Up to hardware upgrade <1.10.1.0 and hardware revision <E0: -25 to 60°C
4) Up to hardware upgrade <1.10.1.0 and hardware revision <E0: -25 to 50°C
Danger!
Operation outside the technical data is not permitted and can result in dangerous states.
Information:
For detailed information about installation, see chapter
50.
Derating
The derating curve refers to standard operation and can be shifted to the right by the specified derating bonus if
in a horizontal mounting orientation.
Module
Derating bonus
At 24 VDC
Dummy module on the left
Dummy module on the right
Dummy module on the left and right
With double PFH / PFH
d
6
X20SC2212
0 to 60°C
0 to 50°C
5 to 95%, non-condensing
Table 5: X20SC2212, X20cSC2212 - Technical data
Table 6: Derating bonus
Data sheet V1.141 X20(c)SC2212 Translation of the original documentation
I/O power supply minus residual voltage
120 mA
Yes
Yes
0 to 2000 m, no limitation
IP20
See section "Derating".
-40 to 85°C
-40 to 85°C
5 to 95%, non-condensing
5 to 95%, non-condensing
Order 1x safety-keyed terminal block separately.
Order 1x safety-keyed bus module separately.
25 mm
+0.2
"Installation notes for X20 modules" on page
X20SC2212
+5°C
+2.5°C
+0°C
+5°C
+0°C
X20cSC2212
-40 to 60°C
3)
-40 to 50°C
4)
Up to 100%, condensing
