ADTRAN Total Access 600R Specifications page 3

Total Access 600R
VoIP Features
I
MGCP signaling independent of Layer 2 Protocol
❏
RTP transport over PPP, Ethernet or ATM/AAL5
I
E&M Wink support on the DSX-1 port (per RFC 3064)
I
RTP / UDP / IP support (per RFC 3550)
I
ATM / AAL2 Bearer (RFC 3180)
I
Session Description Protocol (SDP) support
(per RFC 2327)
I
Support for RFC 2833: "RTP Payload for DTMF Digits,
Telephony Tones and Telephony Signals"
I
Local DTMP detection
I
Ringing
❏
Distinctive ring support
❏
Ring splash support for "do not disturb" feature
I
Far End Tone Generation (Remote Ringback)
I
Stutter Dialtone / Visual Message Waiting Indicator
(VWWI) support
I
Port-to-Port Hairpin call
I
DiffServ Code Point marking
❏
DSCPs marked per Softswitch instructions
or manually configured at IAD
❏
Call Control and RTP packets can be
configured independent of one another
Routing Capability
Ethernet: 10/100Base-T (RJ-45)
I
IEEE 802.3 and 802.11D (MAC Bridging)
I
IP Support: TCP, RIP V1, RIP V2, UDP, ICMP, ARP, UDP
Relay, SYSLOG
I
Layer 2: Frame Relay, PPP (LCP, IPCP, BCP)
support, ATM
I
DHCP server, DHCP client, DHCP relay
I
Copper Mountain Compatible
Security
I
PAP, CHAP, EAP and Radius
I
NAT with multi-point to single-point
I
PAT with DHCP
I
Packet filtering
I
Multi user level password protection
Management Options
Craft Interface
I
EIA-232, physical RJ-48C
Ethernet 10/100 Base T Port
I
SNMP V2 support
I
Full, menu driven TELNET access
I
Software download via TFTP
I
Support for VoDSL gateway management
systems and firmware download
V.35 DTE Interface
I
Data Rate: Nx56 or Nx64 (N=1 to 24)
I
Electrical and Mechanical: CCITT V.35, 34-pin
I
Frame Relay (FRF.5, FRF.8 capable)
Interoperable with the following
Media Gateway Controllers,
Feature Servers & Gateways:
I
BroadSoft BroadWorks (Release 10 MP1)
I
Cisco AS5300 Series Media Gateway
I
Cisco BTS Softswitch
I
Cisco MGX 8000 Series
I
General Bandwidth G6
I
Lucent iMerge
I
Metaswitch VP3500
I
Nuera RDT-8
I
Telica Plexus 9000
I
Sylantro applications switch
Total Access 612/616/624
Rackmount or Wallmount 1175044L1
Total Access 604/608
Battery Backup
Total Access 612/616/624
Wallmount 1175044L2
