Menu Structure and Settings

The menu structure of the pH Mini Controller is split into 2 sections - Readings
and Settings. Toggling between the two menus is achieved by pressing the Menu
button. Once in the Readings or Settings Menu, navigation is achieved through
the Up and Down arrow keys. Settings may be changed by holding down the Edit
button and then pressing the Up or Down arrow keys. The new setting is
automatically saved when the edit button is released. Some Readings can be
zeroed; to do this hold down the Edit button and then press the Down arrow.
Readings
Display pH
Display Dose Count Total (DCT)
Display Dose Count per Hour (DC/h)
Display System Status
Settings
S1 Set Point
S2 Dose Time (secs)
S3 Dose Interval
S4 pH Lower/Raise
S5 Force Dose
S6 Alarm Deviation
S7 Alarm Dose Count
S8 Alarm ON/OFF
S9 Cal pH7
S10 Cal pH4
Ver 5.0 pH Mini Controller Installation Guide (September 2020)
The desired pH Level
The time in seconds that the peristaltic pump
will run to add acid (lower) or alkali (raise)
The time in minutes between doses to
allow for mixing to occur
This switches the controller to dose either acid
(lower) or alkali (raise)
This forces a dose to occur straight away
If the measured pH deviates from the setpoint
by more than this value, the alarm will
sound (if enabled)
If the Dose Count per hour reaches this
value then the alarm is sounded and the
dosing is inhibited (if enabled)
This enables/disables the alarm functions
Calibrate using 7.0pH buffer
Calibrate using 4.0pH buffer
