Pole Mount
www.peplink.com
©Peplink. All rights reserved.
Steps:
1. Place the flat brackets onto
the pole horizontally.
2. Making use of the holes in the
brackets, attach the two
semicircular pole connectors
to the bracket, securing it with
washers and nuts.
3. Insert four long screws with
washers through the holes in
the brackets and into the
designated holes in the BR1
IP67.
4. Tighten the nuts on each
side.
