DIGITAL CURRENT-TRANSFORMER TESTER
Vanguard Instruments Company, Inc.
1520 S. Hellman Ave.
Ontario, California 91761, USA
TEL: (909) 923-9390
FAX: (909) 923-9391
EZCT-2000B
USER'S MANUAL
TM
July 2009
Revision 1
