High Definition Input – We have published the capability to accepting standard
definition input and upconverting the video signal to HDTV resolutions. We are happy
to advise that the HDTV UpConverter can accept HDTV signals from terrestrial set
top box tuners, HD satellite receivers and HDTV Digital Cable boxes through any of
the three (3) Component video inputs. The UpConverter can receive signals at 480p,
720p or 1080i.
1080i pass-through – the HDTV UpConverter can receive a 1080i input signal, however
when the output resolution is also set to 1080i the image will be pillar boxed (black
bars on left and right side) so you may want to display a 1080i input signal at the 720p
resolution or any other lower resolution. An input signal of 1080i will also appear in
Pillar Box mode if 1920 x 540p resolution is selected.
Product Specifications:
Specifications:
Front Panel:
•
Power On/Standby
•
Display showing input, display resolution, TV channel
•
TV Tuning buttons
•
Source and resolution select buttons
Inputs:
•
3 - RCA Video jacks
•
3 - S-VHS jacks
•
3 - Component video jacks (480i/480p, 1080i)
•
1 - 125 channel cable ready tuner
•
9 - R+L RCA Audio jacks
Outputs:
•
1 – HDTV Component jack
•
1 – R + L RCA jack
Video Input:
•
Std. Definition 480 interlaced or progressive scan 480p, and HD sources of 720p and 1080i
Video Output:
•
HDTV 480p, 720p or 1080i resolutions as well as additional output resolutions for fixed pixel
display devices of 852 x 480p, 1024 x 1024p, 1280 x 768p, 1280 x 1024p
Power:
•
Internal Switching Power Supply
•
Input: 110-240 VAC
Requirements:
•
HDTV Ready TV, Plasma, LCD or projector with HD Component Video Inputs (YPbPr)
•
Analog Video source w/RCA, S-VHS or Component Video output or analog TV signal
HDTV UpConverter 9
In t r o du c t i o n
: Pro du c t F e at u re s :
