- Page 1 PYRO 1394b PCI: Add FireWire B to Your Computer User's Guide: First Edition North America Support Hours: M-F : 8 am - 5 pm, PST Email : support@adstech.com website : www.adstech.com Multilingual Manual Tech 810-593...
- Page 2 STEP 1: Power down your computer and disconnect the power cord. Be sure to remove the power cord completely from your computer as shown in the picture above. STEP 2: Remove each screw found on the back of the computer. Be sure to put the screws you removed in a safe place, as you will need them again when replacing the shell on...
- Page 3 STEP 3: Carefully remove the shell from your computer. STEP 4: With the power cable disconnected from your computer, touch the metal part of the case to ground yourself. This will discharge any static electricity from your body which can damage your computer. Schritt 3: Nehmen Sie vorsichtig die Abdeckung von Ihrem Computer ab.
- Page 4 STEP 5: Locate an available PCI expansion slot*, then visually confirm that the PYRO 1394b PCI card will fit into the available slot you have chosen. *For full 800 Mbps bandwidth, you must have a 64-bit PCI slot STEP 6: If necessary, remove the knockout on the back of your computer which corresponds to the PCI slot you...
- Page 5 STEP 7: Push the PYRO 1394b PCI card firmly into the PCI slot. Apply pressure as needed (but do NOT force the card) until the edge connector is completely sealed; if the card is fully seated, then the gold connectors should be completely in the slot.
- Page 6 STEP 9: Replace the computer’s shell and screw it back into place with the screws you removed in “Step 2”. STEP 10: Now that your PYRO 1394b PCI card is installed and the shell is in place, you can now safely connect the power cable.
