MARTHA STEWART LIVING CLOSET STARTER
TOWER W/SHELF ANTIQUE WHITE / NATURAL
Assembly Instructions
HDC #:2944300410/2944300950
MFG #:WSMSL-SKW&WSMSL-SKN
Please read over the instructions; it will be a
time-saver in the long run.
Note: Before Assembly, please be sure to work on a soft flat
surface to avoid any damage to the finish.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Whalen Storage
Factory No.: 15548
Page #1 of 9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection MARTHA STEWART WSMSL-SKW
Summary of Contents for Home Decorators Collection MARTHA STEWART WSMSL-SKW
- Page 1 MARTHA STEWART LIVING CLOSET STARTER TOWER W/SHELF ANTIQUE WHITE / NATURAL Assembly Instructions HDC #:2944300410/2944300950 MFG #:WSMSL-SKW&WSMSL-SKN Please read over the instructions; it will be a time-saver in the long run. Note: Before Assembly, please be sure to work on a soft flat surface to avoid any damage to the finish.
-
Page 2: Assembly Tips
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S SHELF & BOTTOM MAXIMUM LOAD: 30 LBS. (13.6KG) This unit is intended for use only with the maximum weights indicated. - Page 3 Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-abrasive surface. You will need the parts identified on page 3 and 4 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH DAMP CLOTH.
-
Page 4: Parts List
Parts List Please read completely through the instructions and verify that all parts listed are present before beginning assembly. A-Top Panel (x 1) B-Side Panel Left (x 1) C- Side Panel Right (x 1) D- Shelf Panel (x 1) E- Bottom Panel (x 1) F- Stretcher (x 2) G- Back Panel (x 1) Hardware List... - Page 5 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty carton to avoid any scratch. 2. Place the Bottom Panel (E), the Side Panel Left (B) and the Side Panel Right (C) on a level and protective surface with the holes facing up.
- Page 6 Assembly Instructions 6. Insert Wood Dowels (3) into the inner end holes of Top Panel (A), Shelf Panel (D), Stretcher (F) ,Bottom Panel (E) . Tap in with a mallet, if necessary. Make sure you use a small amount of glue with both ends of all dowels. NOTE: It is very important to use a small amount of glue on both ends of dowels.
- Page 7 Assembly Instructions 10. Unfold the Back Panel (G) and lay it to the back edges of the assembled unit, as shown. Make sure the overlaps on the panels are even all the way around. Secure the Back Panel (G) in place using the M2x19 mm Pan Head Screw (4). We recommend attaching the back panel with the screws at the corners first.
- Page 8 Important Notice Please Read Note: The unit is designed to combine with our other product at the same series as shown below for your reference. WSMSL-FSDKW WSMSL-HSDKW WSMSL-SS2W WSMSL-FS2W WSMSL-28PB WSMSL-FSDKN WSMSL-HSDKN WSMSL-SS2N WSMSL-FS2N (Sold Separately) (Sold Separately) (Sold Separately) (Sold Separately) (Sold Separately) WSMSL-V8CDW...
-
Page 9: Tipping Restraint Hardware
TIPPING RESTRAINT HARDWARE We have included one Tipping Restraint Hardware bag (7) for this unit. You must install this hardware to prevent accidents or injuries from falling unit. When properly installed, this restraint can provide protection against the unexpected tipping of the storage rack due to small tremors, bumps or climbing.
