- Page 1 HOME DECORATORS C O L L E C T I O N HDC#97150 MFG#M61267T1-IV/M61267T1-BL MARTIN COFFEE TABLE ASSEMBLY INSTRUCTIONS NOTE:BEFORE ASSEMBLY,PLEASE BE SURE TO WORK ON A SOFT FLAT SURFACE TO AVOID ANY DAMAGE TO THE FINISH Made In China...
-
Page 2: Parts List
Thank you for purchasing this quality product.Be sure to check all packing material carefully for small parts，which may have came loose inside the carton during shipment，Count all parts and material hardware,then compare with parts list to be sure all parts are present.If any parts are missing or damaged，phone，fax，or mail to our Customer Servic Department for efficient and speedy service . - Page 3 1).USE SCREWS (J) TO ATTACH SUPPORTING RAIL (D) TO SHELF (C) WITH SCREWDRIVER (NOT PROVIDED).
- Page 4 2).USE SCREWS (I) TO ATTACH L BRACKET (H) TO SIDE FRAME (B) WITH SCREWDRIVER (NOT PROVIDED).
- Page 5 3).USE SCREWS (J) TO CONNECT SHELF (C) WITH SIDE FRAMES (B) WITH SCREWDRIVER (NOT PROVIDED).
- Page 6 4).POSITION SIDE FRAMES (B) TO TOP PANEL (A) BY USING WOOD DOWELS (E),CAM BOLTS (F) AND CAM LOCKS (G) WITH SCREWDRIVER (NOT PROVIDED).
- Page 7 5).USE SCREWS (I) TO FIX L BRACKET (H) TO TOP PANEL (A) WITH SCREWDRIVER (NOT PROVIDED).
- Page 8 5).INSERT THE WOOD STOPPERS (K) INTO THE GROOVES OF TOP PANEL(A).
