60" [1524]
4" [102]
4" [102]
6-ø1-3/8" [6-ø35]
2-ø1-3/4" [2-ø44]
36" [914]
Installation Manual
• Carefully read the instructions before
starting the installation.
• This vanity should be installed by an
experienced plumber.
• Drain pipe and drain trap are not
supplied. Connect to an existing drain
pipe.
If you are missing any part, please stop
and contact us immediately at:
1-800-986-3460
[1524]
37-1/2"
[953]
4" [102]
4" [102]
Manuel d'installation
• Lire attentivement ces instructions
avant de débuter l'installation.
• Cette vanité devrait être installée par
un plombier professionnel.
• Drain et trappe non fournis.
Connecter à un drain existant.
En cas de pièces manquantes, vous êtes
priés d'arrêter et de nous contacter au:
60"
DIMENSIONS
DIMENSIONS
DIMENSIONES
1-800-986-3460
MELPARK 60
INSTALLATION MANUAL
MANUEL D'INSTALLATION
MANUAL DE INSTALACIÓN
22"
[560]
34-1/2"
[877]
Manual de instalación
• Lea las instrucciones antes de
comenzar la instalación.
• Esta vanidad debe ser instalado por
un experimentado plomero
• Tubo de desagüe y sifón no se
suministran. Conectarse a una
tubería de drenaje.
Si le faltan cualquier parte, por favor
parar y contacto inmediatamente en:
1-800-986-3460
PAGE 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Home Decorators Collection MELPARK 60
Summary of Contents for Home Decorators Collection MELPARK 60
- Page 1 MELPARK 60 INSTALLATION MANUAL MANUEL D’INSTALLATION MANUAL DE INSTALACIÓN 22” [560] 60” [1524] 34-1/2” [877] 37-1/2” [953] DIMENSIONS DIMENSIONS DIMENSIONES 60” [1524] 4” [102] 4” [102] 4” [102] 4” [102] 6-ø1-3/8” [6-ø35] 2-ø1-3/4” [2-ø44] 36” [914] Installation Manual Manual de instalación Manuel d’installation...
- Page 2 PART LIST LISTE DES PIÈCES LISTA DE PIEZAS PART # QUANTITY # DE PIÈCE DESCRIPTION DESCRIPTION DESCRIPCIÓN QUANTITÉ PARTE # CANTIDAD Countertop Comptoir Encimera Backsplash Dosseret Salpicadero Basin Lavabo Lavabo Tilt-down drawer Tiroir rabattable Cajón abatible Door (left) Porte (gauche) Puerta (izquierda) Adjustable shelf Tablette ajustable Estante ajustable Door (right) Porte (droite) Puerta (derecha) Drawer...
- Page 3 INSTALLATION INSTALLATION INSTALACIÓN Silicone Silicona 24H! PAGE 3...
- Page 4 DRAWER TIROIR GAVETA REMOVE INSTALL RETIRER INSTALLER RETIRAR INSTALAR PAGE 4...
- Page 5 SHELF TABLETTE ESTANTE REMOVE INSTALL RETIRER INSTALLER RETIRAR INSTALAR PAGE 5...
- Page 6 MAINTENANCE & CONSUMER RESPONSIBILITIES Stone countertops (Granite, Marble, etc.) are surprisingly resilient to stains and scratches. However, as a preventative measure, any spills on the stone surfaces should be wiped up within a reasonable amount of time. Don’t let liquid sit on the stone overnight. Stones are most prone to staining by oil and acid, so be sure to blot these spills up as soon as they happen. Follow up by cleaning the stone with a mild non-abrasive soap and water. In bathrooms specifically, stone tends to attract soap scum, just like man-made tile. Rinse vanity top with clean, hot water frequently. The use of sealers is also a powerful preventative measure. Your stone was sealed at the factory, but reapplication is necessary over time. How often is determined by the quality of the sealer used, and the frequency of use. We recommend using a penetrating non-toxic sealer for bath areas, but a food-safe sealer is is typically not necessary. If stains and scratches do occur, there are many things you can do as a consumer to remove them. Remove oil based stains with acetone, mineral spirits, or ammonia. Organic stains like coffee, tea, or juice can be removed with hydrogen peroxide, mixed with a few drops of ammonia. Water spots or rings are the most common problem with bath vanities, and are caused by minerals left behind when water evaporates. These can be removed by buffing the spots gently with 00 gauge steel wool. Likewise, small nicks and scratches can often be removed the same way. Larger scratches, chips, and resilient stains may require professional help. Please contact your local stonemason for details. Remember the following list of DOs and DON’Ts: • DO use preventative cleaning measures to keep your stone pristine. • DO use sealers, applied according to the product specific directions. • DO blot spills quickly, and wash with mild soap and warm water. • DON’T use harsh bathroom cleaners or grout cleaners on any natural stone. • DON’T worry if you get a significant stain or scratch that your stone investment is ruined. Virtually anything can be fixed with professional help. ENTRETIEN ET RESPONSABILITÉS DU CLIENT Les comptoirs de pierres tels que le granite ou le marbre résistent très bien à la décoloration et sont pratiquement impossibles à érafler. À titre préventif, il faut toutefois bien essuyer la pierre après chaque utilisation. Évitez d’y laisse r du liquide durant plusieurs heures. La pierre naturelle est plus susceptible de décolorée au contact de l’huile ou de l’acide, donc assurez-vous d’éponger immédiatement la flaque. Terminez en nettoyant avec un savon non abrasif et de l’eau. Plus particulièrement dans les salles de bain, la pierre retient les résidus de savon tout comme les carreaux artisanaux. Rincez fréquemment la surface du meuble-lavabo avec de l’eau chaude. L’application d’un scellant est également fortement conseillée. Un scellant a été appliqué à la manufacture, toutefois suite à une longue utilisation, une nouvelle application est nécessaire. La fréquence de nouvelles applications est déterminée par la qualité du scellant et l’utilisation du meuble-lavabo. Il est recommandé d’utiliser un scellant pour salle de bain. Un scellant de grade alimentaire n’est pas essentiel. S’il y a apparition d’éraflures ou de décoloration, il y a quelques moyens pour s’en défaire. Enlevez les taches d’huile avec de l’acétone, de l’essence minérale ou de l’ammoniaque. La décoloration par liquide naturelle telle que le café, le thé ou le jus se nettoie avec un mélange de peroxyde d’hydrogène et quelques gouttes d’ammoniaque. Dans les salles de bain, les taches d’eau ou les cernes sont le problème le plus fréquent et sont causés par le dépôt de minéraux laissé lors de l’évaporation de l’eau. Ces taches peuvent être enlevées en polissant doucement la surface avec une laine décapage #00. Les entailles et les éraflures peuvent être enlevées de la même manière. Les grosses éraflures, les éclats ou la décoloration persistante requièrent l’aide d’un professionnel. Veuillez faire appel à un maçon pour plus de renseignements.
- Page 7 LIMITED 1 YEAR WARRANTY This warranty applies to the DISTRIBUTOR vanities installed for commercial and residential use. The DISTRIBUTOR warrants that, when installed in accordance with the Recognized Plumbing Industry Practice, the vanities are free of manufacturing defects for a period of one (1) year from the date of purchase. We guarantee your satisfaction with each vanity. Should any vanity not meet your satisfaction due to a visual defect, simply return it to your retailer with the original packaging, PRIOR TO INSTALLATION, for a replacement. This warranty applies only to the original purchaser and installation site and is not transferable. INFORMATION ABOUT YOUR WARRANTY COVERAGE This warranty does not cover damages or failure attributable to: • Vanities installed with obvious visual defects. • Defects or damages to vanities caused by installation that does not comply strictly with the instructions set forth in the DISTRIBUTOR’s installation manual. • Defects or damage to vanities caused by severe accidents (e.g., fire, impacts). • Damage caused by flooding or standing water from leaking pipes, faucets, household appliances, etc; up to and including flooding and any damage caused by acts of God. FOR WARRANTY SERVICE • To make a claim, contact the DISTRIBUTOR no later than 30 days following the date of discovery or detection of defect. • Proof of purchase, such as the bill of sale is mandatory when requesting warranty service. • The DISTRIBUTOR reserves the right to designate a representative to inspect the vanity for analysis. • No unauthorized person, installer, dealer, agent or employee of the DISTRIBUTOR or any representative is entitled to assume any liability on behalf of the DISTRIBUTOR relating to the sale of this product or has the authority to increase or alter the obligations or limitations of this warranty. THE SOLE REMEDY PROVIDED BY THIS WARRANTY IS THE REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCTS. THIS WARRANTY DOES NOT COVER THE COST OF REMOVAL OR INSTALLATION OF NEW PRODUCTS.
