- Page 1 42000 BTU Square Glass Tube Patio Heater item no. 014-HG-PH42 www.bellezefurniture.com FOLLOW US: CONTACT INFO: NOTE: The instruction booklet contains IMPORTANT safety support@bellezefurniture.com @bellezefurniture 1-800-682-6376 information Please read and keep for future reference.
-
Page 2: Our Brand
OUR BRAND PLEASE LIKE, COMMENT AND FOLLOW. TABLE OF CONTENTS... -
Page 3: Safety Information
SAFETY INFORMATION Your safety and the safety of the others are very important. DANGER WARNING CAUTION DANGER WARNING WARNING... -
Page 4: Package Content
PACKAGE CONTENT... - Page 5 （Not include ) Flange...
-
Page 6: Assembly Instruction
ASSEMBLY INSTRUCTION Estimated Time for Assembly 60:00 Attach the wheel assembly to the bottom plate by using 4 pcs of M6 x 12 bolts and 4 pcs of M6 flange nuts... - Page 7 Align the pins on the base to the holes on the bottom of the lower support. Press to secure the pins. Secure the lower support to the base by using 12pcs of 3/16" screws. Align the pins on the control box assembly to the holes on the top of the lower support. Press to secure the pins.
- Page 8 Assemble the block belt to 2 of the lower support by using 4 pcs of M5 x 12 screws. Insert the upper support to the lower support and secure using 8 pcs of 3/16” screws.
- Page 9 Assemble the flame screen on top of the upper support and secure using 8 pcs of 3/16” screws Attach the reflector on top of the flame screen by putting 3 pcs of studs on the flame screen, th 3 pcs of washers. Put the reflector on top, and secure the assembly with another 3 washers and 3 wing nuts.
- Page 10 Carefully install the glass tube by lifting up and insert through the venter hole of the flame screen Make sure the black silicone ring is located at the bottom of the glass tube. Slide the glass tube through the hold of the plate on top of the control box assembly. Check and ensure the glass tube is position properly and is completely cover the center hole of the plate on the control box assembly.
- Page 11 3/16" Screw x 16 M5 X 12 Screw M5 Flange nut Philips screwdriver Attach the 3 side panels to the heater using 12 pcs of 3/16” screws. For the middle 2pcs of holes need use M5 Flange Nut and M5 X 12 Screw. Blocking the lower support on front panel using 4pcs of 3/16"...
- Page 12 Attach the knob on the front panel and the chain on the other side. Secure the knob and chain using a M4 x 10 screw. Hook the other end of the chain to the control box assembly. Insert the pothook of the front panel to the holes on the bottom plate.
- Page 13 Screw gas hose and regulator to a 20 lb propane cylinder. Careful to prevent cross-threading. WARNING: Use a standard 20 lb propane cylinder only. *Use this heater only with a propane vapor withdrawal supply system. See chapter 5 of the standard for storage and handling of liquefied petroleum gas.
- Page 14 WARNING WARNING...
- Page 15 OPERATION INSTRUCTION Leak Check WARNING • All leak test should be performs outdoors. • Extinguish all open flames before testing • DO NOT smoke when perform leak test. • DO NOT use the heater until all connections have been tested and do not leak. 1.
- Page 16 Before Turning Gas Supply ON WARNING This appliance shall be used only in a well-ventilated space and shall not be used in a building, This appliance shall be used only in a well-ventilated space and shall not be used in a building, garage or any other enclosed area.
- Page 17 Lighting This heater is equipped with a pilot light that allows for safer startups and shutdown. Pilot must be lit before main burner can be started. 1. Turn the control knob to the “OFF” position. 2. Fully open the LP cylinder valve 3.
- Page 18 Shut Down Re-lighting WARNING...
- Page 19 Operation Checklist...
-
Page 20: Care And Maintenance
CARE AND MAINTENANCE WARNING Cleaning The Exterior Surface Storage (Between Uses) Storage (During Long Period of Inactivity) -
Page 21: Troubleshooting
TROUBLE SHOOTING... - Page 22 Problem Possible Cause Solution Gas pressure is low Replace with new cylinder Outdoor temperature is below Burner flame is low 40 F and cylinder is less than 1/4 Use a full cylinder full Blockage in orifices Clear any blockage Dirt, film, or carbon built up on Clean the reflector and burner reflector and burner screen screen...
- Page 23 NOTE...
- Page 24 Warranty Register your product on our website to enjoy extended warranty!! Easy Return 1-800-682-6376 support@bellezefurniture.com We hope you enjoy your new Belleze furniture! Share your photos on Instagram and tag us @bellezefurniture. FOLLOW US: CONTACT INFO:...
