48000 BTU Stand Patio Heater
FOLLOW US:
@bellezefurniture
item no. 014-HG-PH00
www.bellezefurniture.com
CONTACT INFO:
support@bellezefurniture.com
1-800-682-6376
NOTE:
The instruction booklet contains IMPORTANT safety
information Please read and keep for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 014-HG-PH00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Belleze 014-HG-PH00

Summary of Contents for Belleze 014-HG-PH00

  • Page 1 48000 BTU Stand Patio Heater item no. 014-HG-PH00 www.bellezefurniture.com FOLLOW US: CONTACT INFO: NOTE: The instruction booklet contains IMPORTANT safety support@bellezefurniture.com @bellezefurniture information Please read and keep for future reference. 1-800-682-6376...

  • Page 2: Table Of Contents

    Every Belleze product is carefully selected to ensure they meet our standards as well as your standards. We believe quality should never be determined by price which is why Belleze is committed to providing high end merchandise at the absolute lowest cost. PLEASE LIKE, COMMENT AND FOLLOW.

  • Page 3: Safety Information

    SAFETY INFORMATION Your safety and the safety of the others are very important. This manual provides many important safety information. Always read and obey all safety message. Keep this manual for future reference. You can be killed or seriously injured if you ⚠DANGER failed to comply to the instruction immediately.

  • Page 4: Package Content

    PACKAGE CONTENT...

  • Page 6: Assembly Instruction

    ASSEMBLY INSTRUCTION Estimated Time for Assembly 60:00 Attach the wheel assembly to the base by lining up the holes and insert 2 M8x16 bolts, then tighten on the other side using 2 M8 flanged nuts Fill the bast with sand to improve the base stability. Loosely attach 3 brackets to the base with 3 M8x16 bolts..
  • Page 7 Assemble the upper pole on the lower pole and tighten using 2 3/16” screws. NOTE: The warning label on the upper pole should be on the same side as the flat plate of the lower pole. Attach the pole assembly onto the support bracket using 6 M6x30 bolts and 6 M6 flange nuts Fully tighten all the bolts to make sure the pole and support bracket are securely attach to the base.
  • Page 8 Cover the support bracket by sliding the cylinder housing from the top. Attach 3 washer and 3 reflector spacer on top of the screen cove . Tighten the reflective space . Then unscrew 4 bolts from the bottom of the control box.
  • Page 9 Insert the head assembly into the pose, then tighten using the bolts removed on step 6. Remove protective cover on the reflecto .
  • Page 10 Slide 1 reflector panel to anothe ,loosely tighten with M6x10 screws, washer, and cap nut. Repeat the procedure to complete assembling all 3 reflector panels togethe . Then assemble the round reflector plate on the reflector panels with M6x10 screws, washer an cap nut.
  • Page 11 Screw gas hose and regulator to a 20 lb propane cylinder. Careful to prevent cross-threading. ⚠WARNING: Use a standard 20 lb propane cylinder only. *Use this heater only with a propane vapor withdrawal supply system. See the standard for storage and handling of liquefied petroleum gas. ANS/ NPFA 58 or CSA B149.1. Your local library or fire department should have this book A minimum of 0.4 PSI supply pressure is required for the propane gas input adjustment.
  • Page 12 ⚠WARNING • A dented, rusted or damaged propane cylinder may be hazardous and should be checked by your propane supplier. DO NOT use a propane cylinder with a damaged valve connection. • The propane cylinder must be constructed and marked in accordance with the specifications for L gas cylinders of the U.S.

  • Page 13: Operation Instruction

    OPERATION INSTRUCTION Leak Check ⚠WARNING • All leak test should be performs outdoors. • Extinguish all open flames before testing • DO NOT smoke when perform leak test. • DO NOT use the heater until all connections have been tested and do not leak. 1.
  • Page 14 Before Turning Gas Supply ON ⚠WARNING Carbon Monoxide Hazard, USE OUTDOOR ONLY • This appliance can produce carbon monoxide which has so smell. Using the appliance in an enclosed space would cause carbon monoxide poisoning, irreversible brain damage or even death. •...
  • Page 15 Lighting This heater is equipped with a pilot light that allows for safer startups and shutdown. Pilot must be lit before main burner can be started. 1. Turn the control knob to the “OFF” position. 2. Fully open the LP cylinder valve. 3.
  • Page 16 • In normal condition, the height of flame is about 2/3 height of the glass tube under “HIGH” position, and about 1/3 height of the glass tube under “LOW” position. • The flame should be stable and bright in blue color with yellow tops. If excessive yellow flam is detected, turn off the heater and consult “...
  • Page 17 Operation Checklist For your safety, perform the following check before each use. 1. Make sure you are familiar with the entire user’s manual and understand all precautions notes. 2. All components are properly assembled and are in good condition to operate. 3.

  • Page 18: Care And Maintenance

    CARE AND MAINTENANCE Visually checking portions of the hose assembly located within the confines of the heater post. Inspect the entire hose assembly at least annually, disassembling the reflector and burner. Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected areas should be leak tested.

  • Page 19: Trouble Shooting

    TROUBLE SHOOTING Problem Possible Cause Solution Cylinder valve is closed Open the valve Clear the tube, replace if Blockage in gas tube or orific necessary Open gas line and bleed it by pressing the control knob in Pilot light won’t light Air in gas line for 1-2 minutes until you smell propane...
  • Page 20 Problem Possible Cause Solution Gas pressure is low Replace with new cylinder Outdoor temperature is below Burner flame is low 40°F and cylinder is less than 1/4 Use a full cylinder full Blockage in orifices Clear any blockage Dirt, film, or carbon built up on Clean the reflector and burner reflector and burner screen screen...
  • Page 22 Warranty Belleze products come with a 1 year warranty from the date of purchase. In any event that the product arrives damaged or missing parts, we are more than happy to provide you with replacement part(s). Register your product on our website to enjoy extended warranty!!
