Summary of Contents for SII IP-7900
-
Page 1: Table Of Contents
Wide Format Solvent Inkjet Printer Guide to prevent media jams U00118209300 Precautions to prevent media jams 2 Media setting procedure Basic operation for printing ◆ Printing workflow overview To print on other media ◆ To print on PVC, Mesh banner, Backlit banner, or Paper 19 ◆ To take-up media in LOOSE winding mode ... -
Page 2: Precautions To Prevent Media Jams
Precautions to prevent media jams The precautions below are recommended to prevent the main causes of media jams: media wave and skew. Carriage If media waves, the sliding carriage may touch the wave, which may damage the Printer. Media wave At printing without winding Note that the media on the platen may bunch up when the front media edge reaches the floor. Media bunches up. Media At printing on paper-based media To avoid media wrinkle, turn off the preheater and printheater. Preheater Afterheater Printheater At setting media Set the media so that the front media edge precedes the front cover. - Page 3 Be sure to set the media perpendicular to the take-up paper tube. If the media is not perpendicular to the paper tube, the media is taken up with skew, which may cause the media wave on the platen. Media Media Perpendicular Perpendicular Paper tube Paper tube Tape Tape At taking up media in LOOSE winding mode With IP-7900 Paper tube flange Flange spacer With IP-7700 Be sure to take up media with paper In the both media supply side and tube flange. media take-up side, without a flange Without paper tube flange, winding spacer, fix the scroller flange to the deviation may cause a media jam. media by pressing the scroller flange ...
-
Page 4: Media Setting Procedure
Media setting procedure Basic operation for printing The fi gures below show the printing workfl ow overview, taking banner ◆ Printing workflow overview for instance. F R O N T REAR REAR REAR F R O N T F R O N T C H E C K E D G E G U A R D ＊O K ? F R O N T S E L E C T ... - Page 5 F R O N T S E T M E D I A ＊O K ? P R E P A R I N G M E D I A P L E A S E W A I T FRONT FRONT FRONT...
- Page 6 ● To set media on the Printer This section explains the media setting procedure, taking banner with IP-7900ʼs fi gure for instance. Put the media on the table. If you want to use a dolly, contact us. We have a recommend product. Set the scrollerʼs scroller fl ange to the roll media. Remove the two screws and move the roll spacer to the center of the media. There are three screwing positions. Roll spacer The roll spacer prevents the paper tube from bending at the center due to the media weight.
- Page 7 Flange spacer Scroller shaft Not required in LOOSE winding mode. Scroller flange Roll spacer Scroller shaft clip Flange spacer Not required in LOOSE winding mode. For outer take-up mode (1) Insert the flange spacer between the scroller flange and the media roll. Roll media Scroller shaft clip...
- Page 8 Set the media-loaded scroller on the scroller fl ange. IP-7900 Flange support Printer rear (supply side) IP-7700 Flange support To set the scroller alone: To set the scroller manually by two persons: Use a recommended dolly. Use the supplied scroller handle. Recommended dolly Scroller handle Scroller Scroller IP-7700 Only Install the fl ange holders. The shape diff ers between the right and left fl ange supports. Wiping unit side Capping unit side Remove the protection bar and open the front Front cover cover. Protection bar...
- Page 9 Move the media edge guards to each side. Cap side Wipe side Move the media edge guards to each side so that they are not under the media. With pressing the media edge guardʼs your side part, move each media edge guard. With pressing the media edge guard’s your side part, move each media edge guard. Set the pressure to “Open” by rotating the Takeup side pressure control knob. Pressure control knobs Insert the media end into the paper feeder. Paper feeder while smoothing out the media by hand to prevent wrinkles. If the media is curled - If it is hard to insert the media end into the paper feeder due to a curl of the media, interpose an interleaf and insert the media end under the interleaf as shown in the fi gure Printer rear below. - Up curl - Down curl Feed media for 1m more after the blip.
- Page 10 Feed back the media. Feed back the media while pressing the center of the media gently at the supply side. Confi rm that the front media edge precedes the closed front cover by approx. 30cm. 30cm Important! - Step 9 is important to set the media properly. Set the pressure to “Normal” by rotating the Takeup side pressure control knob counterclockwise. Point to be checked again - Check whether the media on the platen has no fl oat or wrinkles. Set the media edge guards. (1) With pressing the media edge guardʼs your side part, move each media edge guard to the media edge. (2) Align each media edge guardʼs notch to the media edge. Check that the media edge guards are not under the media or thick media is not caught by inserting it forcibly. Notch With pressing the media Align each media edge edge guard’s your side part, guard’s notch to the media move each media edge edge.
- Page 11 Press the key. C HE C K EDG E G UA RD *O K ? Select [ROLL] and press the key. SE LEC T MEDI A R OLL/S HE ET :R OL L Either [roll] or [sheet] can be selected with the or R OL L / SHE ET :S HE E T key.
- Page 12 Tension bar length Examples of tension bar combinations Tension barʼs total length Tension bar combination IP-7900 IP-7700 16 inches (41 cm) 16 inches (41 cm) 16 inches（41 cm） 16 inches（41 cm） 24 inches（61 cm） − − 26 inches（66 cm） 24 inches (61 cm) S、S 32 inches（82 cm） 32 inches（82 cm） M、S 40 inches（102 cm） − 48 inches (123 cm) ML、S − 42 inches（107 cm） 48 inches（123 cm） 48 inches（123 cm） M、S、S 56 inches（143 cm） − ML、S、S − 58 inches（148 cm） L、S 64 inches（164 cm） 64 inches（164 cm） 16 inches (41 cm) 16 inches (41 cm) L、M 72 inches（184 cm）...
- Page 13 ● To load media on take-up reel This section explains the procedure, taking in TENSION winding mode for instance. Install a paper tube on the IP-7900ʼs scroller or on the IP-7700ʼs scroller shaft and scroller fl ange. Remove the two screws and move the roll spacer to the center of the media. There are three screwing positions. Paper tube Roll spacer: The roll spacer prevents the paper tube from bending at the center due to the media weight. Scroller Roll spacer Do not move this roll spacer. Flange stopper Flange spacer Paper tube Insert the scroller into the paper tube, determine the distance between the media edge and the flange. Flange Knob Paper setting gauge Attach the paper setting gaugeʼs (1) The flange spacer has teeth. Push it as far as flange side to the it will go. flangeʼs spoke side. (2) Match the flange stopper with the claw of the flange spacer Rotate the handle clockwise as far as it (3) Tighten the knob to secure the flange will go, and then secure the scroller at the ...
- Page 14 Flange spacer Not required in LOOSE Roll spacer winding mode. Scroller shaft Scroller shaft clip Flange spacer Scroller shaft clip Not required in LOOSE winding mode. Paper tube Scroller flange (1) Insert the flange spacer between the scroller flange and the media Knob roll.
- Page 15 Hook the tension bar to the tension bar hook Tension bar hook beforehand. Tension bar Attach the IP-7900ʼs scroller or the IP-7700ʼs scroller fl ange. IP-7900 Scroller Roll groove IP-7700 Scroller fl ange Roll groove By pressing the key, feed the media until the front media edge is wound on the paper tube. F EEDI NG M EDI A...
- Page 16 Install the printed media to the paper tube. (1) Check the take-up direction, remove the slack of the media, and then make sure that the media is not deviated on the supply side and the takeup side. Paper (2) With tape hold the media straight at the center, and tube then at the rest six positions in the direction from the media center to the media edge. Tape Inner take-up: Outer take-up: Media is taken up with its Media is taken up with its print print surface coming inside. surface coming outside. Points to be noted on winding media - If the media is not installed straight to the paper tube, a skew of media may occur. - When the take-up direction is set as Inner take-up, the taken-up media's diameter increases and the media cannot backfeed after printing. Select [FWD ONLY] beforehand in MEDIA BACK MODE of MEDIA REG MENU. (When the media backfeeds in [BACK&FWD] mode, the motor idles and may cause a trouble.) Set the take-up direction switch according to Take-up direction switch the take-up direction. Outer take-up - O FF Inner take-up By pressing the key feed the media, and wind one full turn of the media on the paper tube. F E E DING MEDIA CAUTION - ...
- Page 17 By pressing the key, feed the media until the front media edge is wound on the paper tube. F EEDI NG M EDI A Be sure to create a suffi cient slack so that the tension bar is placed at the bottom of the tension bar guide. Open the tension bar guideʼs cover. Place the tension bar at the bottom of the tension bar guide. When the tension bar does not reach the tension bar guideʼs bottom - When the tension bar does not reach the tension bar guideʼs bottom, feed the media with the operation panelʼs FEED menu. Confi rm that tension bar was placed securely at the tension bar guideʼs bottom. Close the tension bar guideʼs cover. When the excessive media slack is created - If the media slack is secured excessively, the take-up reel unit may keep winding the media for more than the prescribed time, and a take- up timeout error occurs. In such a case, turn off the take-up direction switch, and then press the switch again. Input the data in the software RIP.
-
Page 18: To Print On Other Media
To print on other media ◆ To print on PVC, Mesh banner, Backlit banner, or Paper Media ● Winding mode Supply-side tension bar LOOSE winding mode Install an S-size tension LOOSE winding mode bar at the slack center position. ● Supply-side tension barʼs size S size ● Printer setting For glossy PVC For matte PVC # M E D I A B A C K M O D E S E L E C T M E D I A S E L E C T M E D I A M E D I A : G l o s s y M E D I A : M a t t e... - Page 19 Media Backlit banner ● Winding mode Supply-side tension bar TENSION TENSION winding mode Install a tension bar winding mode conforming with the media width. ● Supply-side tension barʼs size Length conforming with the media width ● Printer setting # M E D I A B A C K M O D E A f t 5 0 P r n 4 0 P r e 4 5 S E L E C T M E D I A >...
-
Page 20: To Take-Up Media In Loose Winding Mode
◆ To take-up media in LOOSE winding mode ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ To prevent media winding deviation, set the paper tube fl ange to the scroller. Note that the rubber spacers are required depending on the paper tube length as explained below. Rubber spacer A Rubber spacer B Rubber spacer C (1 pc) (1 pc) (1 pc) Paper tube fl ange (2 pcs) Paper tube, longer than the media width Media メディア Rubber Rubber Rubber spacer A spacer B spacer C Paper tube flange Paper tube Attach the paper tube flange to the paper tube. Paper tube, at length conforming with the media width Rubber spacer A Rubber spacer C Rubber Rubber Rubber spacer A spacer B spacer C Paper tube flange Paper tube Rubber spacer Bʼs application When the paper tube's inner Media diameter is not sufficiently longer ... - Page 21 Install a paper tube to the scroller. Remove the two screws and move the roll spacer to the center of the media. There are three screwing positions. Paper tube Roll spacer Do not move this roll Scroller spacer. Flange stopper Flange spacer Paper tube flange Paper tube Run the paper tube through the two paper tube flanges so that each paper tube flange's fixing screw side would face outward.
- Page 22 Mount the scroller to the take-up roll. which will make the operation easier from this step. By pressing the key, feed the media until the front media edge is wound on the paper tube. F E E DING MEDIA Adjust the paper tube fl ange position. By loosening the handle, adjust the paper tube position or the paper tube fl ange position so that the distance between the media edge and the two paper tube fl anges would be 3 to 5mm. After the adjustment, fi x the paper tube by rotating the handle. Rubber spacer C Media Media Flange Flange Handle Handle Paper tube Paper tube flange Paper tube Paper tube flange Clear this gap. Media Paper tube Paper tube flange...
- Page 23 Fix the paper tube fl ange. Evenly tighten the three screws on the paper tube Media fl angeʼs external side. Paper tube flange fixing screw Paper tube (at three positions) flange By rotating the take-up roll, confi rm that each of the two paper tube fl anges does not swing right and left. To rotate the take-up roll (1) Cover the sensor window by sliding your Sensor window hand downward as shown by the arrow of the left fi gure. Note that the take-up roll is rotated only with the sensor's downstroke shielding. (2) By keeping the sensor window covered, the take-up roll rotates for 4 seconds and stops. (3) When the take-up roll needs to be rotated more, repeat the steps (1) and (2). Load media on the paper tube in outer take-up mode. With adhesive tape, hold the media straight at the center, and then at the rest positions in the direction from the media center to the media edge. CAUTION Paper tube Tape - ...
- Page 24 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ CAUTION - Apply the paper tube with the same length with the media width. Prepare the paper tube for installing the scroller Paper tube fl anges. (1) Insert the scroller fl ange into each edge of the paper tube. Scroller fl ange (2) Turn the handle clockwise until the scroller fl anges are fi xed to the paper tube. Handle Scroller fl ange Set the take-up direction switch to OFF. Take-up direction switch Outer take-up CAUTION - O FF - If the printer processing proceeds to the next step with the take-up direction switch set to ON, your Inner take-up hand may be caught as the scroller fl ange is not secured. Scroller fl ange Set the scroller fl anges installed on the paper tube on the printer so that the scroller fl...
- Page 25 Install the printed media to the paper tube. (1) Check the take-up direction, remove the slack of the media, and then make sure that the media is not deviated on the supply side and the takeup side. (2) With tape hold the media straight at the center, and then at the rest six positions in the direction from Paper tube the media center to the media edge. Tape Inner take-up: Outer take-up: Media is taken up with its Media is taken up with its print surface coming inside. print surface coming outside. Points to be noted on winding media - If the media is not installed straight to the paper tube, a skew of media may occur. - When the take-up direction is set as Inner take-up, the taken-up media's diameter increases and the media cannot backfeed after printing. Select [FWD ONLY] beforehand in MEDIA BACK MODE of MEDIA REG MENU. (When the media backfeeds in [BACK&FWD] mode, the motor idles and may cause a trouble.) Press the take-up direction switch according to Take-up direction switch the take-up direction. Outer take-up - O FF Inner take-up By pressing the key feed the media, and wind one full turn of the media on the paper tube. F EEDI NG M EDI A Again set the take-up direction switch to OFF.
- Page 26 By pressing the key, feed the media so that a slack area is created in the media. F E E DING MEDIA Press the take-up direction switch according to Take-up direction switch the take-up direction. Outer take-up When the excessive media slack is created - O FF - If the media slack is secured excessively, the Inner take-up take-up reel unit may keep winding the media for more than the prescribed time, and a take- up timeout error occurs. In such a case, turn off the take-up direction switch, and then press the switch again.
