- Page 1 CXL12A Powered Processed Stage Monitor USER MANUAL revision 2020-07-28...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 3 FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 4 MECHANICAL DRAWING ....5 CXL12A PRESET RESPONSE ....7 OPTIONAL ACCESSORIES .
- Page 5 32.2 cm 12.7" OPTIONAL ACCESSORIES CASECXL12 NC3MXXBAG Carrying Case for 2 box unit Neutrik XLR-M COVERCXL12 Cover for CXL12A NC3FXXBAG Neutrik XLR-F NAC3FCA Neutrik Powercon® BLUE PLUG NAC3FCB Neutrik Powercon® WHITE PLUG see http://www.axiomproaudio.com/ for detailed description and other available accessories.
- Page 6 MAINS OUT - Powercon® NAC3FCB power output connector (grey). This is connected in parallel with the MAINS ~ / IN. The maximum load applicable depends on the mains voltage. With 230V~ we suggest to link a maximum of 4 CXL12A loudspeakers, with 120V~ we suggest to link a maximum of 2 CXL12A loudspeaker.
- Page 7 FOH LOW CUT This PRESET is the same as FOH but with a low cut at 110 Hz 48 dB/oct. To be selected when a CXL12A is used in combination with a subwoofer to form a main system or as FRONT FILL system. It can be used also in case you need to cut drastically the LF response.
- Page 8 PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com...
