STI-CO CTUN-NB-VHF Installation Considerations

CTUN Installation Considerations
VHF Field Tunable Antenna
CTUN-NB-VHF
The CTUN-NB-VHF is a field tunable antenna that operates in a 3 MHz bandwidth across the frequencies of
150-174 MHz. Once tuned to the desired frequency, the locking mechanism holds the tuning assembly in place.
This omni-directional, vertically polarized (from bottom edge) antenna can be concealed in a tissue box on the
rear deck of a vehicle, placed between two boards, hidden in a sign, or mounted in countless covert ways.
VERIFY:
1. Part List: The system package includes CTUN-NB-VHF antenna with cable, mounting feet and Velcro
mounting strips. Use only components supplied with the antenna system (Refer to Parts List).
Part
CTUN-NB-VHF
CI-543
CK-199
HK-177
2. Bandwidth: The tunable VHF antenna has a bandwidth that is 3 MHz wide. This antenna is tunable
between the frequencies of 150 MHz and 174 MHz.
SET UP:
1. Procedure:
a. Tune CTUN to the desired frequency (refer to section Tuning section on sheet 2).
b. Attach CK-199 to CTUN antenna and radio.
c. Attach Velcro (Figure 1) or circuit board stand (Figure 2) to CTUN Antenna for mounting.
d. Place antenna where desired.
ci-543
Description
VHF Narrowband CTUN Antenna
Customer Instruction
SMA Male to customer connector of
choice
Hardware Kit: MP-185 Velcro Hook
(QTY 3), MP-186 Velcro Loop (QTY
3), H-1348 Circuit board Stand(QTY
2)
Page 1 of 3
Made in U.S.A.
Qty Inspected By
1
1
1
1
REV 000
