Katadyn Steripen Adventurer Opti User Manual

Adventurer
Steripen
User's Guide
Katadyn North America
4380 Azelia Ave. N
Minneapolis, MN 55429
help@katadyn.com
www.katadyn.com
ADO.UG.E.1901 © 2019 Katadyn Group
® ®
PERFORM BETTER. PACK LESS.
Thanks for choosing the Steripen®
Adventurer Opti and congratulations
on your purchase.
Adventurer Opti is built to be safe, simple
and straightforward. If, after reading this
guide, you have any questions please
don't hesitate to call us at help@katadyn.com
We love hearing from you.
Also, be sure to visit us online and register
your Adventurer Opti for all the latest
news and special deals.
Thanks again and happy travels
from your friends at Steripen.
P.S. Don't forget to recycle the packaging.
EASY TO USE
STEP 1
Remove lamp cover.
Pull straight off and away
from the lamp.
STEP 2
Press activation button.
1x for 1 liter treatment,
2x for 0.5 liter treatment.
STEP 3
Submerge and stir.
Ensure blinking water sensor is
immersed. UV lamp will illuminate.
Water sensor will flash. Water sensor will flash.
When lamp turns off, LED indicator will display When lamp turns off, LED indicator will display
treatment success or failure (see "Adventurer Opti treatment success or failure (see "Adventurer Opti
LED Indicator Guide section"). LED Indicator Guide section").
After purifying, be sure to wipe bottle After purifying, be sure to wipe bottle
threads dry before drinking. threads dry before drinking.
ADVENTURER OPTI'S ANATOMY
1 Lamp cover
1
2 UV lamp
2
3 Optical water sensor
4 Activation button
5 Indicator LED
6 Battery compartment cap
7 Battery compartment screw
SPECIFICATIONS
3
Treatment size: 0.5 or 1 liter
Treatment time: 48 or 90 seconds
Lamp life: 8,000 activations
Treatments per set of batteries:
up to 50 (30 with rechargeables)
Minimum bottle opening: 38mm
Weight: 103g (including batteries)
Size: 155 x 40 x 24mm
FLASHLIGHT
4
Turn on/off flashlight
by holding down
5
activation button for
3 seconds. Flashlight
will turn off automatically
after 3 minutes.
6
7
BATTERY GUIDE
STEP 1
Loosen battery
compartment screw to
open battery compartment.
STEP 2
Install two CR123
batteries with
polarities as shown.
STEP 3
Tighten coin screw on
end cap until snug.
Do not overtighten.
Adventurer Opti runs on lithium disposable
CR123 or rechargeable RCR123 batteries.
For best results, always use quality,
name brand batteries.
To avoid battery performance being affected
by cold weather, carry them close to your body
to keep them warm.
CARE & CLEANING
While Adventurer Opti's battery compartment is
designed to be highly water-resistant, it is not
waterproof. Avoid submerging Adventurer Opti's
battery compartment end in water.
Adventurer Opti's performance may be adversely
affected by cold weather. In temperatures below
32ºF/0ºC carry the unit close to your body or warm
up batteries before use. If batteries are too cold,
Adventurer Opti's LED indicator may give low
battery signal. Warm up batteries and treat again.
Make sure to wipe dry after each use.
When not in use, Adventurer Opti should be kept in
a safe place that is clean and dry. It should not be
exposed to temperatures above 120°F/49°C or below
-4°F/-20°C. Also, when storing Adventurer Opti
for prolonged periods, remove batteries to avoid
draining them while not in use.
To clean Adventurer Opti, wash with a soft cloth
and a mild soap solution. Rinse soap from device
and dry with a clean, soft cloth.
If Adventurer Opti's bulb is cracked, chipped or
damaged, don't use it. Return it to the store or
contact us for repair. Email us at help@katadyn.com. Do
not try to
fix it yourself.
LED INDICATORS
PRE-TREATMENT
(repeating sequences)
Ready for treatment
Not submerged in water in time
POST-TREATMENT
(repeating sequences)
Successful water treatment (1L)
Successful water treatment (½L)
Successful water treatment,
batteries low (1L)
Successful water treatment,
batteries low (½L)
Successful water treatment, UV lamp
good for less than 100 uses (1L)
Successful water treatment, UV lamp
good for less than 100 uses (½L)
Water not detected
Replace or recharge batteries
Check, replace, or recharge batteries
Replace UV lamp, UV lamp damaged
If LED indicators show normal signals, but the lamp does not illuminate,
do not consume. Contact Steripen® support.
